The Fully Automatic Operation of Bag Opening!
See the machine operation video at our website: /automatic-bag-opening-machine.html
Keywords:
Automatic Sack Opening Machine, Automatic Bag Opener, Automatic Bag Slitter, Automatic Bag Opening Station, Automatic Bag Opening & Emptying Station
INTRODUCTION:
The discharging of powders, flakes, pellets and other types of bulk materials from bags/sacks can be one of the most time consuming, labor intensive and hazardous processes in industry. ZJY ZBO-A series Automatic Bag Opener is designed for automatic, continuous, dust-free and fast operation of loading, opening and compacting of bags with a range of 20-50kg. Suitable bags can be paper bags, plastic bags, poly-woven bags or burlap sacks.
HOW IT WORKS:
During operation, the bag is firstly fed into the bag slitting station of ZBO-A series Automatic Bag Openerby a powered belt conveyor. The bag is then lifted from the conveyor to the positioning station, from where the bag is pushed by the pneumatic mechanism to the cutting station.
At the cutting station, a clean and neat cut, driven pneumatically with a sharp blade, is made through the whole bag and makes it into two halves, and then another lifting mechanism will lift the two halves at an angle, while special claws will penetrate into the bags and hold them. The bulk materials drop into the collection hopper at the bottom due to the gravity; meanwhile, pneumatic pistons will vibrate the two half bags so that the powder residues are also shaked out of the bags.
After the bag is emptied, the new bag at the positioning station will push the two half bags into the waste bag collection station, where they are packed by the bag compactor for further disposal.
The enclosed design of the bag slitting station is equipped with a dust collecting hood to collect the dust.
FEATURES & ADVANTAGES:
The ZBO-A series Automatic Bag Opener is featured for:
1. Quick and complete cutting to eliminate contamination of bag fragments
2. High throughput of max. 300 bags per hour (ZBO-A-300)
3. Able to handle bags of different sizes
4. Low residual (min. 0.1%) to avoid any waste of the materials
5. Enclosed structure to eliminate dust issues to the workers and environment
6. Compact construction to save the valuable space
7. To be built in carbon steel, SS304, SS316L, etc
8. Dust collecting device or fitted into the existing dust collecting system
STANDARDS & OPTIONS:
Standard configuration of ZBO-A series Automatic Bag Opener includes:
1. Belt conveyor to load bags
2. Automatic bag opening & emptying station
3. Bag compactor to collect waste bags
4. Dust filtering system
5. Electric control system with PLC
6. Construction built in carbon steel
Options are available:
1. Sieving & Screening system
2. Construction built in SS304 or SS316L
APPLICATIONS:
Our ZBO-A series Automatic Bag Opener is used in a broad range of industries (chemical, rubber, plastic, food, pharmaceutical, wastewater treatment, etc) when the bulk materials are packed in the bags and fast and continuous opening operation is required.
SPECIFICATIONS:
Model |
ZBO-A-50 |
ZBO-A-300 |
Bag size |
20-50kg |
|
Capacity, kg |
50 bags/hour |
300-400 bags/hour |
Frame material |
Carbon steel or SS304/SS316L |
|
Drive of cutting knife |
Pneumatic |
Motorized |
Air consumption |
0.6NM3/min |
- |
Options |
Dust collector, Waste bag collector, etc. |
|
1. All specifications are as accurate as is reasonably possible, but they are not binding.
2. Customized sizes are available against request.
3. ZJY reserves the right to modify the design without notice.
