Spur Gear Cutting With Hobbing Machine Video And Gear Hobbing Machine Specifications
MODEL:Y3180H spur gear cutting
The Y3180H gear hobbing machine could produce straight teeth and helical teeth,cylindrical spur teeth,worm gear,chain wheel and short spline shaft, and this hobbing machine suitable for in bulk and single production .The gear hobbing machine has the auto off function ,safety device and self-lubrication system .
Specification |
Unite |
Y3180H |
Max.dia.of workpiece (without back column/with back column) |
mm |
800/550 |
Max.modulus(casting iron/steel workpiece) |
mm |
10/8 |
Max. helix angle in turning bevel gear |
° |
±45° |
Max. dimension of cutter (Dia. x Length) |
mm |
180x180 |
Cutter tool spindle taper hole |
MS |
No.5 |
Worktable diameter |
mm |
650 |
Worktable hole diameter |
mm |
80 |
Worktable mandrel tapper |
Ms |
No.5 |
Distance between axis of cutter and work table face |
mm |
235~585 |
Distance from hob center to workable center |
mm |
50~550 |
The distance between under end surface of the support bearing hole and the worktable |
Mm |
400-600 |
Rapid moving speed of work table |
mm |
50 |
Max. axial movement of cutter |
mm |
50mm(manual) |
Spindle speed steps |
|
8 |
Spindle speed range |
rpm |
40~200 |
Axial feeds range |
mm/rev |
12 steps 0.4~4 |
The max speed of worktable |
r/min |
5.3r/min (3.5r/min) |
Power of main motor and synchro-speed |
kw/rpm |
5.5/1500 |
Power of rapid axial motor and synchro-speed |
kw/rpm |
1.1/1500 |
Power of hydraulic pump motor and synchro-speed |
kw/rpm |
1.1/1000 |
Power of rapid worktable motor and synchro-speed |
kw/rpm |
O.55/1500 |
Power of cooling pump |
kw |
|
The net weight |
Kg |
5500kg |
Overall size |
mm |
2750*1490*1870 |
The gear hobbing machine has the auto off function ,safety device and self-lubrication system
We welcome customized machine , could provide tangential cutter head,processing the worm wheel as the tangential feeding .
1.Convenient hydraulic powed structure reduces the non-cutting time as well as the times to use the cutting tools .
2.Raised height for vertical column and increased stroke:The vertical column is made higher(180/130mm increased axial stroke in head slide)
3.High precision and long service life:The machine adopts the worm gear of a high precision over five grade and uses bronze alloy material which is of high abrasion resistance,enabing long service life and steady accuracy.
Tengzhou Borui CNC Machine tool Co.,Ltd is an integrated company ,which set development, production, sales as one .Our factory establishes in 1980 years ,have over 30 years history ,what's more ,we are comprehensive manufacturer.
Our Company’s CNC lathe, machining center, drilling machine, hydraulic machine and gear hobbing machineexport to many countries. Especially in Egypt, Saudi Arabia, Turkey ,we have good customer base, also export to South America and other countries.
The company with innovative ideas that developing market, and
always with good quality. Reasonable price, accurate delivery and quality service ,we set a good image in the customer .
For machine: Usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Plywood
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have
Q: How do we confirm the accuracy and performance of machines?
A: (1) Regarding the performance ,we could produce a workpiece for your consult ,which will be produced according to the customer's sample that send to us.
(2)You could inspect machine accuracy by online video
(3)You also could check our factory and machine quality by SGS or other Inspecting Authority.
Q: Can you change the voltage of machine?
A: Sure,we can , We can change the voltage according to different area. 110V-220V-380V-400V-440V
Q: What's the delivery time after payment ?
A: It need about 30 days if the machine is customized .and it just need about 20 days if your machine is universal .
Q: How long is your quality guarantee period?
A:One year, if machine has problem, we will provide accessories in free, in the meantime, we can use DHL or TNT express delivery.
We guarantee that if customers have questions, we will reply within 8 hours, and develop a set of complete solutions according to customers’ problems.
