The types of our products include home villa elevator, marine elevator, clean elevator,explosion -proof elevator, mine lift, debris elevator ,stereo lifting equipment, special passenger, freight elevators, other customized production of elevator.Our elevators are greatly appreciated in a variety of different markets throughout the world
| load(kg) | rate of speed | car size | well size | opening size | pit depth | overhead height | generator room size |
| 360 | 0.63/1.0 | 1100*900 | 1750*1900 | 700 | >=1500 | >=4000 | 1750*2500 |
| 450 | 0.63/1.0 | 1350*900 | 2000*1900 | 700 | >=1500 | >=4000 | 2000*2500 |
| 630 | 0.63/1.0 | 1400*1100 | 2100*2100 | 0 | >=1500 | >=4000 | 2100*2500 |
| 800 | 0.63/1.0 | 1400*1350 | 2100*2350 | 800 | >=1500 | >=4000 | 2100*2500 |
| 1000 | 0.4 | 1400*1500 | 2250*2250 | 900 | >=1500 | >=4000 | 2250*2500 |
| 100 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
| 200 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
| 300 | 0.4 | 1000*1000 | 1500*1400 | 1000 | NO | >=2500 | 1500*2400 |
The main configuration
items |
Parts name |
brand |
producing area |
comments |
|
1 |
Control cabinet |
Microcomputer control system |
Step |
Shanghai |
Assembly |
Variable frequency driving |
step |
Shanghai |
|||
Master contactor |
Schneidder |
Shanghai(joint venture) |
|||
Relay |
Omron |
Shanghai(joint venture) |
|||
Air switch |
Delixi |
Shanghai(joint venture) |
|||
Phase sequence |
Ait |
Ningbo |
|||
2 |
Tractor |
Permanent magnet trction machine |
Tongrun |
Suzhou |
Assembly |
Rotary encoder |
Heidenhain |
France |
|||
3 |
Maneuvering box |
maneuvering box panel |
Ok |
Shanghai |
|
microcomputer operation panel |
Xinshida |
Shanghai |
|
||
display in the cabin |
Xinshida |
Shanghai |
|
||
4 |
Calling box out cabin |
calling board out cabin |
OK |
Shanghai |
|
Display of showing floors |
Xinshida |
Shanghai |
|
||
5 |
Cabin |
cabin assembly |
Kangchi |
Shanghai |
|
emergency power supply in the cabin |
OK |
Shanghai |
|
||
6 |
Safety parts
|
speed governor |
Olin |
Shanghai |
|
Safety tongs |
Letian |
Shanghai |
|
||
buffer |
Lvdun |
Shanghai |
|
||
light curtain |
Weike |
Ningbo(joint venture) |
|
||
7 |
steel rope |
Tianshen |
Tianjin |
|
|
8 |
Door opener |
permanent magnet synchromous motor |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
Frequency converting contro |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
||
Machine parts |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
||
9 |
Rail |
Hongcheng |
Suzhou |
|
|
10 |
Rail bracket |
Kangchi |
Shanghai |
|
|
11 |
Traveling cable |
Changshun |
Shanghai |
|
|
12 |
Cabin door |
Kangchi |
Shanghai |
|
|
13 |
Landing door |
Kangchi |
Shanghai |
|
|
14 |
Little door frame |
Kangchi |
Shanghai |
|
|
The above is the standard configuration. If you want have a high quality, the configuration can be adjust. But it cannot be lower than the basic configuration.
Trade & Market
Main Markets: Mid East
South America
North America
Domestic Market
Southeast Asia
Central America
Western Europe
Africa
Eastern Asia
South Asia
Total Annual Sales Volume: US$1 Million - US$2.5 Million
Export Percentage: 61% - 70%
“Kangchi” is located in Shanghai, China, which is specialized in designing and making all kinds of elevator ,such as:villa/home elevator, passenger elevator, boat elevator, clean elevator, anti-explosion elevator, mine elevator, dumbwaiter, freight elevator and so on for finished elevator factories and end-users.“Kangchi” has gained the production license and elevator installation qualification certificate. It has achieved ISO9001:2008 international quality system standard certification.
Service
As the professional manufacturer of elevators, Shanghai Kangchi have stringent safety criterion in international elevator industry.In order to provide professional services for the modernization market, According to the various special requirements from the clients, Shanghai Kangchi will provide more reliable, more maturity and more economy solutions.
Installation
The final assembly of elevators are conducted on site, which is the most important chain in assembly. We will send professional project manager to be responsible for internal planning, coordination, distribution of labor, project quality management and safety management of the installation project. Prior to the launch of each project, the project manager shall hold internal inaugural meeting to develop construction scheme and exchange technical documentations, and develop emergency scheme according to actual situations, so as to guarantee the project is completed in line with quality requirements and without delay. We constantly develop the latest elevator installation workmanships in order to remain at the world-leading level. Compared with traditional elevator installation workmanships, installation without scaffold saves a lot of trouble in erecting and dismantling scaffolds, standardizes installation procedures, shorten the installation period and improve its quality. COMPOSED Elevator will provide you with best product quality, best project quality and best service quality.
Maintenance
We have always attached great importance to the development of maintenance technologies. And, in the light of properties and application environment of different elevators, we has developed unique maintenance procedures as well as special computer and tools. In addition to routine maintenance, we will inspect your elevator periodically with special presumptive diagnostic technology and develop personalized maintenance scheme according to your elevator’s operation conditions, to protect against possible troubles and maximize its operation time.
Renewal and Reconstruction
We will appropriately apply new technology, feature and material to in-service elevator to expand its functions, improve operation reliability and traveling comfort, and further satisfy special demands of customers.
