ship elevator
- 30 Unit / Units per Month
- Shanghai port
- T/T
- Homogenization tank B200 external fluidization plate homogenization tank inflation equipment
- B400 Electro-hydraulic sector valve Pneumatic sector valve Block material sector valve can be customized
- Bulk material bulk hangar bottom cement clinker sand aggregate loading inside the wear-resistant ceramics
- Air transport chute XZ400 cement plant ash chute dry ash ore powder transport equipment
- SZT-300 clinker bulk machine sand aggregate bulk head fixed car loader
- Cement depot bottom arc discharge valve B300 pneumatic flow control valve Electric flow control valve
Product Details
Place of Origin: | Shanghai, China | Brand Name: | composed | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
The types of our products include home villa elevator, marine elevator, clean elevator,explosion -proof elevator, mine lift, debris elevator ,stereo lifting equipment, special passenger, freight elevators, other customized production of elevator.Our elevators are greatly appreciated in a variety of different markets throughout the world
load(kg) | rate of speed | car size | well size | opening size | pit depth | overhead height | generator room size |
360 | 0.63/1.0 | 1100*900 | 1750*1900 | 700 | >=1500 | >=4000 | 1750*2500 |
450 | 0.63/1.0 | 1350*900 | 2000*1900 | 700 | >=1500 | >=4000 | 2000*2500 |
630 | 0.63/1.0 | 1400*1100 | 2100*2100 | 0 | >=1500 | >=4000 | 2100*2500 |
800 | 0.63/1.0 | 1400*1350 | 2100*2350 | 800 | >=1500 | >=4000 | 2100*2500 |
1000 | 0.4 | 1400*1500 | 2250*2250 | 900 | >=1500 | >=4000 | 2250*2500 |
100 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
200 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
300 | 0.4 | 1000*1000 | 1500*1400 | 1000 | NO | >=2500 | 1500*2400 |
The main configuration
items | Parts name | brand | producing area | comments | |
1 | Control cabinet | Microcomputer control system | Step | Shanghai | Assembly |
Variable frequency driving | step | Shanghai | |||
Master contactor | Schneidder | Shanghai(joint venture) | |||
Relay | Omron | Shanghai(joint venture) | |||
Air switch | Delixi | Shanghai(joint venture) | |||
Phase sequence | Ait | Ningbo | |||
2 | Tractor | Permanent magnet trction machine | Tongrun | Suzhou | Assembly |
Rotary encoder | Heidenhain | France | |||
3 | Maneuvering box | maneuvering box panel | Ok | Shanghai |
|
microcomputer operation panel | Xinshida | Shanghai |
| ||
display in the cabin | Xinshida | Shanghai |
| ||
4 | Calling box out cabin | calling board out cabin | OK | Shanghai |
|
Display of showing floors | Xinshida | Shanghai |
| ||
5 | Cabin | cabin assembly | Kangchi | Shanghai |
|
emergency power supply in the cabin | OK | Shanghai |
| ||
6 | Safety parts
| speed governor | Olin | Shanghai |
|
Safety tongs | Letian | Shanghai |
| ||
buffer | Lvdun | Shanghai |
| ||
light curtain | Weike | Ningbo(joint venture) |
| ||
7 | steel rope | Tianshen | Tianjin |
| |
8 | Door opener | permanent magnet synchromous motor | Best/Zhanpeng | Shanghai/Zhanpeng |
|
Frequency converting contro | Best/Zhanpeng | Shanghai/Zhanpeng |
| ||
Machine parts | Best/Zhanpeng | Shanghai/Zhanpeng |
| ||
9 | Rail | Hongcheng | Suzhou |
| |
10 | Rail bracket | Kangchi | Shanghai |
| |
11 | Traveling cable | Changshun | Shanghai |
| |
12 | Cabin door | Kangchi | Shanghai |
| |
13 | Landing door | Kangchi | Shanghai |
| |
14 | Little door frame | Kangchi | Shanghai |
|
The above is the standard configuration. If you want have a high quality, the configuration can be adjust. But it cannot be lower than the basic configuration.
