Specifications
Professional clean energy manufacturerQuality guaranteed
Competitive price
Delivery in time
Great servic
High efficiency turbine generator
1.Raw material ZG0Cr13Ni4Mo
2.Certificate ISO9001`2008
3.Lifespan 30~50years
4.Efficiency 90%
5.SGS& BV&TUV certified
6.Competitive price&good quality
7.Customized design
Main products profiles:
There are two types of turbines that are manufactured in our company, they are reaction turbines and impulse turbines.
1.Reaction turbines
Reaction turbines generally mean Francis turbine and Axial flow turbine.
1.1 Francis turbine: applicable water head:30-700m, efficiency: 88%-92%
1.2 Axial flow turbine: applicable water head:2-40m, efficiency: 88%-92%
2.Impulse turbines
Impulse turbines generally mean Turgo turbine and Pelton turbine.
2.1Turgo turbine: applicable water head:40-300m, efficiency: 78%-85%
2.2 Pelton turbine: applicable water head: 50-1300m, efficiency: 86%-91%
Note: We can produce all the four types of turbine as above.
Company brief
1.Water turbine generator
We specialize in water turbine manufacturing for over 40years. The water turbines we supplies severs a wide range of costumers in and out of China.
2.Easy installation & operation
We have a wide range of water turbines for building hydraulic generating systems.It is designed of
easy installation and operation.
3.High efficiency
The water powder generating unit can be applied in varies place and environment.Our water turbine is produced with high efficacy via our long years experience of research and development.
4. Oversea projects
We have exported water turbine generator sets to the following places:
Vietnam——April,2007(2*3200KW)
Peru——November,2007(2*1250KW)
Burma——December,2008(2*400KW)
Burma——November,2009(2*200KW)
Albania——July,2011(2*1250KW,1*630KW,2*400KW)
Indonensia----August,2012(1X4400KW)
For Pelton turbine, You can find the general specification as below.
1. Also called a free-jet turbine or Pelton wheel, a type of impulse turbine.
2. Suited to high head, low flow applications.
3. Can contain up to 6 nozzles.
4. Applicable net head 50m to 1000m.
5. Efficiency 85% to 95%.
6. Life span 30 to 50 years.
For Turgo turbine, You can find the general specification as below.
1.A type of impulse turbine, similar to pelton turbine but can handle higher flow rates.
2. Applicable net head 40m-300m.
3. Unit capacity 50KW to 20MW.
4. Efficiency 85% to 95%.
5. Life span 30 to 50 years.
For Kaplan turbine, You can find the general specification as below.
1. A propeller-type of water turbine, evolution of the Francis turbine with adjustable blades, widely used throughout the world in high-flow, low head power production.
2. Head ranges from 2m to 40m.
3. Runner diameters from 2m to 8m.
4.Turbine range from 79rpm to 429rpm.
HPGE offer a comprehensive range of hydroelectric power plant solution that cover the entire scope of service including, to learn more, pls. do not feel hesitate to contact me!
Contact person: CoCo Wen
Mobile: 86 15228976155
Skype: CoCo.Wen4
If you have any questions, pls. feel free to contact us! We promise you a professional service!
