Out door pressure resistance jelly filled 100% copper long distance communication telephone cable HYVP/ HYV
- 90000 Kiloampere / Kiloamperes per Month
- Shenzhen/ Guangzhou
- T/T D/P D/A Credit Card PayPal
You May Like
-
100pairs bare copper HYVP out door electric telephone cable for high quality telecommunication
-
Outdoor 50pair high speed good quality long distance HYVP telephone cable
-
2core solid bare annealed copper wire 1core galvanized steel messenger high speed communication telephone cable
-
HYV HYA cable shield rj45 connector HYV4x1/0.5mm BC rj11 telephone cable
-
China hotsale 4core screened rj 11 telephone cable white color 0.4mm bare copper conductor high qulaity communication cable
-
Flat Indoor parallel telephone cable HYV 2*1/0.4mm CCS BC CCA conductor long distance communication cable
Product Details
| Place of Origin | Guangdong, China | Brand Name | LINKINDUS | |
| Model Number | Telephone Cable | Type | Coaxial | |
Product Description
Out door pressure resistance jelly filled 100% copper long distance communication telephone cable HYVP/ HYV
What is the sepecfication of telephone cable?
| Part Number | 5P-2400P Telephone Cable(0.4) | 5P-1200P Telephone Cable(0.5) | ||||
| Conductor | Diameter(mm) | 0.4±0.01 | 0.5±0.01 | |||
| Material | Bare Copper | Bare Copper | ||||
| Type | Solid | Solid | ||||
| Dielectric(Insulation) | Diameter(mm) | 0.7mm | 0.9±0.01 | |||
| Material | Solid PE | Solid PE | ||||
| CORE WRAPPING | Material | plastic tape | plastic tape | |||
| shield( for optional) | Material | Aluminium Tape or Steel Tape | Aluminium Tape or Steel Tape | |||
| Thickness(mm) | 0.22-0.25 | 0.22-0.25 | ||||
| Jacket(sheath) | Diameter(mm) | 7.5-70 | 8.5-65 | |||
| Thickness(mm) | ≥1-3.2 | ≥1-3.2 | ||||
| Material | LDPE/PVC | LDPE/PVC | ||||
| Armored ( Steel tape) | For optional | |||||
| Double Jacket | For optional | |||||
| Messanger ( Aerial) | For optional | |||||
| Conductor Resistance(ohms/km ) | ≤147 | ≤92 | ||||
| Insulation resistance(Gohms*km ) | ≥10 | ≥10 | ||||
| Mutual capacitance(nF/km ) | 50±2 | 50±2 | ||||
| Capacitance Unbalance(Pf/km) | Pair-Pair | ≤145 | ≤145 | |||
| Pair-Ground | ≤750 | ≤750 | ||||
| Dielectric Strength | Pair-Pair | DC 1000V/1Min | DC 1000V/1Min | |||
| Pair-Ground | DC 3000V/1Min | DC 3000V/1Min | ||||
| Attenuation | 150kHz(dB/km) | ≤12.1 | ≤9.0 | |||
| 1024kHz(Db/km) | ≤27.3 | ≤22.3 | ||||
| Number of Pairs | 5-2400 | 5-2400 | ||||
| Impedance (ohms ) | 100 | 100 | ||||
| Weight (kgs/km) | 60-7500 | 75-7500 | ||||
| Operating Temperature Range(℃) | -50 to 60 | -50 to 60 | ||||
| package | 305-4000meters/roll | 305-2000meters/roll | ||||
1, OEM/ ODM support
2, Wooden drum or as client's needs
Main Products:
1) Electrical copper wires(rigid and flexible);
2) Communication cables (solid and stranded);
3) Coaxial cables(RG6,RG59,RG59 with power...);
4) Control cables with screens, shielding or other features;
5) Power cables armored or non-armored and with other features;
6) Telecommunication cables including data cables and telephone cables;
7) Instrument cables, particularly RUBBER cables;
8) Fiber optic cable(FTTH,GYTA,GYTS,ADSS,GYTW...)
9) Special cables of Arctic grade, Fire-resistant, Oil-resistant & according to customers' requirements.
Payment | T/T,L/C,D/P,Paypal,Western Union,MoneyGram,based on your quantity |
Delivery time | Within 10 days,finally based on your quantity |
Sample | Sample is free,we cooperate with DHL,TNT,UPS,FEDEX,EMS,China Air Post, ect |
Port | Guangzhou/Shenzhen |
MOQ | 10rolls |
Discount | We can offer when your order is over 50000meters |
