shenzhen oem&odm pcba assembly
- 120000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | ONLITEX | Model Number: | Pcba oem |
Base Material: | FR4 | Copper Thickness: | 1.0oz | Board Thickness: | 1.6mm |
Min. Hole Size: | 0.12mm | Min. Line Width: | 0.12mm | Min. Line Spacing: | 0.12mm |
Surface Finishing: | HASL(LF) |
Product Description
Specifications
Specifications1, Quotation within 5 days
2, Pcba oem
3, Qulity smt pcb assembly service
4, On-time delivery
shenzhen oem&odm pcba assembly
Our PCB fabrication capacity:
Item | Manufacturing Capability |
Material | FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminium, Metal based |
Layer No. | 1~12 layers |
Finished Board thickness | 0.2 mm-3.8mm’(8 mil-150 mil) |
Board Thickness Tolerance | ±10% |
Cooper thickness | 0.5 OZ,1.0OZ,1.5OZ and 2 OZ (18 um-75 um) |
Copper Plating Hole | 18-40 um |
Impedance Control | ±10% |
Warp&Twist | 0.007 |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) |
Min Trace Width | 0.1mm (4 mil) |
Min Space Width | 0.1mm (4 mil) |
Min Annular Ring | 0.1mm (4 mil) |
SMD Pitch (a) | 0.3 mm(12mil) |
BGA Pitch (b) | 0.3 mm (12mil) |
Min Solder Mask Dam (a) | 0.0635 mm (2.5mil) |
Soldermask Clearance (b) | 0.1mm (4 mil) |
Min SMT Pad spacing (c) | 0.1mm (4 mil) |
Solder Mask Thickness | 0.0007"(0.018mm) |
Min Hole size (CNC) | 0.2 mm (8 mil) |
Min Punch Hole Size | 0.9 mm (35 mil) |
Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm |
Hole Position Tol | ±0.075mm |
Plating | |
HASL | 2.5um |
Lead free HASL | 2.5um |
Immersion Gold | Nickel 3-7um Au:1-5u'' |
OSP | 0.2-0.5um |
Panel Outline Tol (+/-) | CNC: ±0.125mm, Punching: ±0.15mm |
Beveling | 30°45° |
Gold Finger angle | 15° 30° 45° 60° |
Dongguan Onlitex Electronic Co. Ltd. is an China professional and competitive manufacturer(factory) that focus on pcb design & manufacture and marketing service of consumer & industrial electronics products.
Packaging
Items per carton: 2000Pieces /Carton
Package Measurements: 46x46x36 cm
Gross Weight: 20KG
Package Type: 1pcs/ESD bubble bags k=k Honey carton box
PCBA PCB Full assembly capability
- Full experienced QC and inspector
- Strong sourcing ability in relative parts and components
- Experienced technical staffs in charge of product design
- Circuit boards 1 to 28 layers PCB layout, fabrication, PCB assembly and box build
- Enclosure cabinet case plastic injection molding, metal stamping, manufacturing and assembly
- High-precision 0201 size components SMT technology and lead-free
- RoHS compiant SMT, DIP process
- IC pre-program
- High-precision E-Tesing include: ICTin circuit, function tesst, etc.
Manufacturing capability
- PCBA Size: 457x567cm(max);4x3cm(Min)
- IC Pitch(min):0.2mm
- Chip Size(min):0402 /1005(1.0x0.5mm)
- BGA Size:8x6mm~37x37mm
- BGA Pin Count: 48pin~600pin
- Package: SOP/SSOP/PLCC/QFP/QFN/BGA/FBGA/u-BGA
- u-BGA Ball diameter: 0.2mm
Pcba oem Trade Term:
1. Payment: T/T, LC,DA,DP,Paypal.
2. Lead time: 10 working days for normal products(components less than 100pcs on pcb board).
3. Samples can be available within 8~10working days
4. Shipping port: Shenzhen or HongKong
5. Discount is offered at larg order quantities
Please keep reading the following about our services
- PCB Layout Design and Assembly
- Mechanic Sample & Prototype Prepare
- PCB Assembly
- electronic Product OEM/ODM
- Mobile Power bank
- Network IP Camera
- Smart home
- ID Design
- Mechanic Design
- Packing Design
- Final Product Assembly
Contact Us
