4 doors 4 seats electric
, 4 seats, Swiss design, 48V system, 8pcs 185Ah T105 batteries, maximum speed of 40km/h, range of 80kms
EG6043K, electric people mover, 4 seats, Swiss design, 48V system, 8pcs 185Ah T105 batteries, maximum speed of 40km/h, range of 80kms
Key Components
Item |
Description |
Controller |
Curtis controller, 275A-400A, imported from USA directly |
Motor |
Rated power 4KW-5KW (5.4HP-6.8HP), Chinese brand or ADC brand |
Battery |
Trojan battery, T105+, imported from USA directly |
Charger |
High frequency onboard charger (input 90V-265V, 47-63HZ, output 48V/22A) |
Performance
Item |
Description |
Passenger Capacity |
4 |
Range (loaded) (km)* |
up to 105 |
Max.speed (km/h) |
up to 40 |
Min.turning radius (m) |
4 |
Max.climbing ability(loaded) |
up to 25% |
Max. movement after brake at speed of 20km/h |
≤4m |
Max.loading weight (kgs) |
450 |
Charging time (hour) |
8-10 |
Battery lifespan (cycles) |
750 |
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
Item |
Description |
Overall dimensions (mm) |
3060x1400x1900 (LxWxH) |
Min.ground clearance (mm) |
155 |
Wheelbase (mm) |
2080 |
Front wheel tread (mm) |
1210 |
Rear wheel tread (mm) |
1160 |
Body and Frame
Item |
Description |
Frame & Chassis |
Welded steel framework with sand blasting and painting |
Body |
FRP and Plastic |
Roof |
FRP with steel frame, with roof handle |
Windshield |
Laminated glass with wiper |
Roof supports |
Plastic |
Seat |
Reborn sponge with artificial leather, high back, with adjustable armrest |
Rear storage box |
Plastic, with lock |
Seatbelt |
3-point type |
Floor |
Bamboo floor with Skidproof leather |
Dashboard |
FRP, with F/R switch, emergency light switch, digital meter, combination switch, storage box (2), etc.. |
Side rear view mirror |
2pcs |
Electric System
Item |
Description |
Lights |
12V, headlight, front turning light, taillight (brake light and rear turing light) |
Horn |
Electric horn, 12V |
Reverse buzzer |
Electric, 12V |
Combination switch |
including switch for headlight, turning light, wiper and horn |
DC/DC converter |
48V/12V |
Digital Meter |
with Current meter, voltometer, speedometer, odometer and various indicators |
Audio system |
Radio with MP3 receiver and 2 waterproof speaker |
Steering & suspersion
Item |
Description |
Steering System |
Single-stage rack and pinion steering system, with automatic compensation function |
Brake System |
4-wheel hydraulic drum brake with hand park brake |
Accelerator |
Resistance type, stepless speed change |
Front suspension |
Independent suspension |
Rear suspension |
integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
Driving mode |
Rear axle two stage deceleration, motor direct driving |
Rear axle |
Integrated, Aluminum differential case, 12.76:1 gear ratio |
Wheel & Tyre |
225/55b12 6PR tire, 12X7 aluminum wheel |
Option Accessories
To increase the sales value of our vehicles, we also provide many optional accessories.
Item |
Option description |
Item |
Option description |
1 |
Inner rear view mirror |
5 |
CD player |
2 |
Battery watering pipe |
6 |
Wired mircophone |
3 |
Water pump (handle) |
7 |
Solar panel (built in) |
4 |
Rain cover |
|
|
Container loading qty |
assembled |
20'ft GP |
1 |
40'ft GP |
3 |
40'HQ |
3 |
All electric vehicles sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
* 13 months warranty
* technical support
* full spare parts support
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd. was founded 1999, and it's a leading manufacturer specialized in designing and manufacturing 4-wheel electric vehicles, includes: electric golf cart, electric utility car, electric personal carrier, electric shuttle bus, electric industrial car, various customized electric vehicles based on standard ones, etc.. It has a workshop area of 20,000 square meters with 2 assembly lines inside. Its daily production capacity is 80 units per day; this can be adjusted with the order volume increasing. It has around 300 workers including 50 engineers in R&D department and 15 engineers in QC department.
Payment Terms:
"T/T 30% down payment at order, T/T 70% to be paid before the delivery" Or Irrevocable L/C at sight
Lead time:
Four Weeks after getting your down payment or original L/C
MOQ:
We dont have minimum order requirement but may apply extra cost for sample unit
