Specifications
Vibrating Feeder:1.short linear type&feed big raw materials
2.simple structure&good continuity
3.adjustable excitation force
Linear vibrating Feeder/High Frequency Machine made in China with Good Price
1.CZW Vibrating Feeder Specifications
Model |
Hopper |
Max Feed Size |
Frequency |
Capacity |
Power |
CZW3815 |
3800x960 |
500 |
~800 |
100-200 |
15 |
CZW4419 |
4875x1124 |
650 |
~800 |
110-400 |
18.5 |
CZW5224 |
6100x1320 |
800 |
~800 |
100-500 |
30 |
CZW5824 |
6096x1475 |
1020 |
~800 |
200-550 |
37 |
| CZW7024 | 6100x1820 | 1500 | ~800 | 200-950 | 55 |
CZG-100 |
1300x700 |
210 |
970 |
100 |
0.55x2 |
CZG-200 |
1600x800 |
270 |
970 |
200 |
0.75x2 |
CZG-300 |
1800x900 |
300 |
970 |
300 |
1.1x2 |
CZG-400 |
1900x950 |
300 |
970 |
400 |
1.1x2 |
CZG-500 |
1900x1250 |
300 |
970 |
500 |
1.5x2 |
CZG-750 |
2200x1400 |
400 |
970 |
750 |
2.2x2 |
2. CZW Vibrating Feeder Introduction
Vibrating Feeder is the latest short linear type feeder that we disign for feeding big raw materials evenly and gradually before primary coarse crusher in crushing and screening plant. It has features of simple structure, even feeding, good continuity, and adjustable excitation force. It can be easily operated by changing and controlling feed amount at any time. With eccentric shaft and vibrating motor as its vibration source, it has advantages of low noise, low power consumption, good adjusting performance, and non-existence of sudden material rush. Vibrating feeder is an indispensable equipment in crushing and screening plant that can deen materials evenly and continuously into crusher, and also it has a function of pre-screening.
3.Main advantages of CZW Vibrating Feeder
It has features of simple structure, even feeding, good continuity, and adjustable excitation force. It can be easily operated by changing and controlling feed amount at any time.
4.CZW Vibrating Feeder are appropriate for
Vibrating feeder is an indispensable equipment in crushing and screening plant that can deen materials evenly and continuously into crusher, and also it has a function of pre-screening.
|
|
|
|
|
|
5.About us
Shanghai Chuangshen Heavy Machinery CO., Ltd is a high-tech industrial enterprise which is professional in designing, manufacturing, marketing, assembling, installing and debugging various jaw crushers, impact crushers, cone crushers, VSI crushers, hammer crushers, roll crushers, screen-type crushers, grinding mill, complete crushing and screening plant and sand making plant.
Our products are widely applied in mining, building materials, metallurgy, railway, highway, water conservancy chemical, and coal industries, and are well distributed both in domestic and global markets.
We keep developing by taking the road of market-oriented, enterprise-led, university-industry cooperation, and gathering the best social resources. We not only have mining industry’s top talent work in our company, but also establishing a long-term cooperation with Shanghai Institute for Advanced Research of Chinese Academy of Sciences to bring innovation and new change to traditional manufacturing industry.
Based on the core value of “Honesty, create value for customers”, we earnestly performs the ISO9001 Quality Management System, constantly innovates new products which have been authorized with new patents, and play an active role in industry development by creating a set of industrial and national standards. We have been rated as AAA Credit Qualification Enterprise, and are the council member of Shanghai Stone Industry Association-Sand Branch, and also the member of CHMIA(China Heavy Machinery Industry Association). Now oversea agents have been rapidly expanded.
|
|
|
|
|
|
|
6.Support
We can not only provide the good machines, but also wholeheartedly provide the comprehensive for our clients. The series of professional technology service will make you have an excellent product experience.
After-sales service support
After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the perfect goods trading services, until the product you purchased properly to your hands.
We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc.
Technological support
Shanghai Chuangshen has been largely adopting new technologies, new techniques and high-tech equipments. And we also have strict and effective quality control system. We have obtained ISO9001:2000 quality system certificate.
We insist on providing clients with overall solutions from equipment recommendation to debugging and installation, worker training, technical.
