Large Capacity Belt Conveyor Widely Used in Mining/chemistry

Large Capacity Belt Conveyor Widely Used in Mining/chemistry photo-1
US$ 100 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Belt conveyor
Application:
sand making, modern construction, water conservancy, minning,etc., Sand making, modern construction, water conservancy, minning,etc.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Belt conveyor
Application sand making, modern construction, water conservancy, minning,etc., Sand making, modern construction, water conservancy, minning,etc.
Motor Type AC Motor
Power(W) According to the model
Capacity(t/h) 40~1284, 40~1284
Place of Origin Shanghai, China
Brand Name TRUSTON
Model Number Belt conveyor
Dimension(L*W*H) According to the model
Weight According to the model
Certification ISO & CE
Warranty One year for main frame(excluding wear parts)
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Large capacity belt conveyor used in mining
Easy to maintain
High transfer capacity
Long transfer distance
ISO & CE

Large Capacity Belt Conveyor Widely Used in Mining

 Large capacity belt conveyor widely used in mining/chemistry




1. Belt Conveyor



Chuangshen's belt conveyors are adaptable for stationary and mobile crushing plants. They are widely used in mining, metallurgical and coal industry to transfer sandy or lump materials, or packaged materials.



2. Belt Conveyor Specification



Belt Width(mm) Belt Length(m)  /  Power(kw) Belt Speed(m/s) Capacity(t/h)
400 <12
1.5-2.2
12-20
2.2-4
20-30
3-7.5
1.25-1.6 40-80
500 <12
1.5-3
12-20
2.2-5.5
20-30
3-7.5
1.25-1.6 78-191
650 <12
1.5-4
12-20
2.2-7.5
20-30
4-11
1.25-1.6 131-323
800 <6
1.5-4
6-15
2.2-7.5
15-30
4-15
1.25-1.6 278-546
1000 <10
2.2-5.5
10-20
4-15
20-40
7.5-37
1.25-2.0 435-853
1200 <10
3-7.5
10-20
4-15
20-40
7.545
1.25-2.0 655-1284
1400 <10
3-11
10-20
4-18.5
20-40
7.5-55
1.25-2.0 655-1284
1600 <10
3-15
10-20
5.5-22
20-40
7.5-30
1.25-2.0 655-1284
Large capacity belt conveyor widely used in mining/chemistry Large capacity belt conveyor widely used in mining/chemistry
Large capacity belt conveyor widely used in mining/chemistry Large capacity belt conveyor widely used in mining/chemistry
Large capacity belt conveyor widely used in mining/chemistry Large capacity belt conveyor widely used in mining/chemistry



Large capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistryLarge capacity belt conveyor widely used in mining/chemistry
