2013 Eu hot sell heat pump for pool and spa water treatment 84kw

Specifications

Swimming Pool Heat Pump
1.12 years manufacturing experience.
2.OEM & Customized service.
3.Profitable Price

meeting heat pumps; hot sell heat pumps; water treatment heat pump

2013 Eu hot sell heat pump for pool and spa water treatment 84kw











Meeting Swimming Pool Heat Pump MDY200D Parameter Table



MODEL		Unit	MDY200D
Rated heating capacity		KW	84
Average heating input power		KW	19
Rated heating input current		A	35
Max outlet water temp		C	35
COP			4.5
Power		V/Hz	380V/50
Noise		Db(a)	65
Dimension	W*D*H	mm	2040×1100×2000
Packing size	W*D*H	mm	2080×1150×2130
Unit weight		KG	650
Refrigerant			R417A/R407C
Working air temp range			(-20°C)—45°C
compressor	Type		Copeland
Air source heat exchanger	Type		Finned heat exchange
	Fan Type		axial flow fan
Hot water side heat exchange	Type		Titanium heat exchanger
	Water flow	L/H	28000L/h
	Water pressure down	Kpa	60
	Pipe size	DN	50





Meeting Swimming pool heat pump water heater uniques:

1. High temperature 60 degree C outlet water. Can replace directly any exisiting boiler. Great product for house upgrade for cost saving.

2. Easy installation, easy maintenance, trouble free product.

3. Extrimly energy saving.

5. All water access parts are stainless steel and copper to keep safe, healthy and non-pollution

6. Automatic star-up and shut down, automatic defrosting. Can be controlled by timer setting

7. compressor: Use world famous compressor brand--copeland scroll compressor, high efficiency, low noise, long lifetime features, with R417A/R407C/R404A Refrigerant , safe and environmentally friendly.

8. condenser: use titanium material , anticorrosive. special for swimming pool water.

9.  expansion valve: use electric expansion valve, and adjust refrigerant flow automatically.



Components for meeting pool heat pump







Packaging Details for meeting pool heat pump

1>Standard Export Package (Exterior Plywood Case & Interior Plastic Films)
2>Bottom fixed with Screws to make sure delivery stablility.
3>Dimension: W: 2040 D: 1100 H: 2000 (mm)
4>Packing Size: W: 2080 D: 1150 H: 2130 (mm)









1. OEM service

2. Customized service: change cabinet (stainless steel cabinet), water to air heat pump production for special needs, add BMS control function (one computer could control many heat pumps)





Certificates for meeting pool heat pumps







More optiom of meeting hot sell heat pumps





1. Which price terms do your company could accept?

It depends on your choice. FOB, CIF, DDU, CAF, etc



2. What is the payment we could accpet?

Generally, T/T is the most frequently we used payment.



3. Can I choose my own forwarder?

Yes, of course you can. And we will charge some fee. Like Documents fee, Clear custom fee, ENS fee.



4. If I do not know how to choose a suitalbe heat pumps, what can I do?

Please kindly inform me the area of place, air temperature, and water flow etc information, I would like choose the most suitable heat pump to you.



5. What if I want buy some spare parts from your company?

Welcome, generally, the spare parts could delivery to your door in 5 to 7 days. However, Freight would be expensive. So, you could buy it with heat pumps.



6. Any discount If I place a large order?

Yes,  we could talk details.



7. What if there are some problems of the machine?

Any problem, please kindly inform me. I am ready to answer in any time.
