Help CenterPressure Screen for Paper Pulp Making
Related Products
-
Upflow Pressure Type Screen / Single Drum Pressure Screen for Pulp/ Pulper for Paper Processing MachineryNegotiableMOQ: 1 Set -
Fiber Separator MachineUS$ 1 - 10,000MOQ: 1 Set
-
Double Disc Refiner for Paper MachineNegotiableMOQ: 1 Set
-
Disc Refiner for Paper PulpNegotiableMOQ: 1 Set
-
Mechanical Pulp RefinerNegotiableMOQ: 1 Set
Usage: Pulp enters into screen in tangent direction under relatively high pressure,
so the fiber and coarse foreign particles have already been separated before pulp
enters screen drum by the centrifugal force. The qualified fiber will pass through
screen drum with the help of differential pressure at pulping inlet and outlet. At the
same time, high-rotating rib plates play the role of cleaning surface gaps on screen
drum. Comparing with other types of screening equipments, under the condition of
same driving force and screening area, this screen has better screening efficiency
and pulping quality.
Technical parameters :
model |
SLNS-1 |
SLNS-2 |
SLNS-3 |
SLNS-4 |
Screen drum area(m2) |
0.6 |
1.2 |
2 |
3 |
Screen drum slit width(mm) |
0.15-0.55 |
|||
Pulping-in pressure(mpa) |
0.1-0.25 |
|||
Pulping –out pressure(mpa) |
0.01-0.04 |
|||
screening concentration(mpa) |
1.0-2.0 |
|||
production capacity(t/d) |
20-60 |
25-90 |
40-150 |
50-250 |
Motor power(kw) |
15-18.5 |
22-30 |
37-45 |
55-75 |
