ZDP series double disc pulp-grinding machine
Application
To grind various pulps, the equipment can be used alone, also can be arranged in a series.
Double disc pulp-grinding machine by grinding pulp chamber transmission mechanism base and other components of the motor grinder by fixed in the cabinet room and mobile seat two fixed grinding slice and installation disk in the two rotating grinding slice, form two grinding area through the changing different toothed abrasive disc, in order to adapt to all kinds of pulp beating requirements.
Feature
High efficiency and low power consumption.
It is horizontal type double disc pulp grinding machine that pulp enter from the two sides of double disc area.
Use of mechanical seal, more dependable.
Compact structure and convenience to maintenance.
The pulp outlet and diameter of inlet pipe are enlarged; So that it more adjust to improve the concentration of pulp and enlarging the quantity of flow.
| Type | Φ380 | Φ450 |
| Diameter of refiner plate(mm) | 380 | 450 |
| Product capacity(t/d) | 6-20 | 8-60 |
| Concentration of input pulp(%) | 2-5 | 3.5 |
| Pressure of input pulp(Mpa) | 0.1-0.2 | 0.15-0.2 |
| Motor power(Kw) | 37 | 75,90,110 |
