Exercise Book Paper Making Machine from Waste Paper and Recycled Paper
- 1 Set / Sets per Month
- Qingdao Port
- T/T Credit Card PayPal
- A4 Size Copy Paper Production Machine for Small Business
- Small Notebook Paper Making Machine with Capacity of 5 Tons/Day
- A4 Copy Paper of 80 GSM Paper Production Machine
- Paper Sheet Making Machine for A4 Copy Paper and Writing Paper
- Paper Notebook Production Line for Waste Paper Recycling
- Printing Paper Making Equipment from Raw Material of Printing Off-Cuts Quality Choice
Product Details
Condition: | New | Type: | Other, Printing Paper Cultural Paper and News Paper Machine | Computerized: | Yes |
Place of Origin: | Henan, China | Brand Name: | Dingchen | Model Number: | Exercise Book Paper Machine |
Voltage: | 240V-380V | Power(W): | 240W-380W | Dimension(L*W*H): | N/A |
Weight: | N/A | Certification: | ISO9001:2008 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Containers, wooden boxes, boards and other materials required
Product Description
Exercise Book Paper Making Machine from Waste Paper and Recycled Paper
1. Raw material: Waste paper (waste office paper/book paper/printing factory off-cuts/newspaper/magazine), virgin pulp, wood pulp board, bagasse, cotton stalk, wood chip, wheat straw, reed, rice straw
2. Output paper: Cultural Paper/Printing Paper/Duplex Paper/News Paper/Writing Paper
3. Output paper weight: 50-100g/m2
4. Capacity: 1-10 tons per day
5. Net paper width: 1092mm~3200mm
6. Wire width: 1092mm~3200mm
7. Working speed: 80-120m/min
8. Designing speed: 200m/min
9. Rail gauge: 1300mm-3900mm
10. Drive way: AC frequency converter speed control, section drive
11. Layout: Left or right hand machine
Note: different model has different specifications
Main Structures
1. Cylinder mold section: Stainless-steel cylinder mold 2set,couch roll 3 set(including 1 reverse roll), rubber coated with shore hardness 38℃±2
2. Pressing section: natural marble roll 1 set, rubber roll 1 set with shore hardness 92℃±2, pneumatic pressure device
3. Drying section: Alloy dryer cylinder 2 sets, touch roll 1 set with shore hardness 92℃±2, pneumatic pressure device
4. Winding section: winding cooling drum 1 set
NO. | Equipments | Qty(set) |
1 | Culture paper machine | 1 |
2 | Dryer can exhaust hood | 1 |
3 | Axial ventilator | 1 |
4 | Roots Vacuum Pump | 1 |
5 | Suction box | 6 |
6 | Winding machine | 1 |
7 | Rewinding machine | 1 |
8 | High consistency hydrapulper | 1 |
9 | Highfrequency screen | 1 |
10 | Desander | 1 |
11 | Centrifugal screen | 1 |
12 | Double disc refiner | 2 |
13 | Bleacher | 1 |
14 | Thruster | 2 |
15 | Pulp pump-100 | 4 |
16 | Pulp pump-150 | 2 |
17 | Frequency conversion control cabinet | 1 |
18 | Air pump cabinet | 1 |
19 | Working table | 1 |
20 | Boiler | 1 |
Our Advantages
1. Competitive price
2. 30 years’ professional experience in design and manufacturing of paper making machines
3. Advanced technology and state of art design, stringent testing and quality inspection process
4. Extensive experience in overseas projects, including plant design, installation, test run, staff training, production and maintenance consultation
5. Extensive experience in products customization to meet client’s special requirements
Contacts
Company Profile
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.
Our company has over 420 employees. We have passed ISO14001 International Authentication. Our products include paper making machines, parts and paper processing machines such as kraft paper machines, tissue paper machines, cultural paper machines, fiber separators, hydrapulpers, rewinders, napkin folders, tissue slitters and so on. They have been exported to more than 8 countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc.
Relying on advanced technologies, sincere services and inexpensive products of high quality, we have won the recognition of international markets and clients.
