1092mm Model 4tpd High Grade White Writing Paper Making Machine For Paper Mill
Introduction:
For complete writing paper making machine, There are THREE Main Parts:
1.Pulping equipment ( Different Raw Material: Waste Paper, Virgn Pulp Board, Mixed Pulp. )
2.Writing paper making machine ( Different Paper Width, Paper Weight, Production Capacity. )
3.Paper processing equipment ( Different type according to customer's requirement.
Note:
Financial Analysis can be provided if customers' need to compare with cost of different Raw Materials.
Technical Parameter
1. Raw material: Waste paper
2. Output paper: Med-quality Culture paper, Writing Paper, Printing Paper, Newspaper
3. Output paper weight: As customer's requirement
4. Capacity: 4 tons per day
5. Net paper width: 1092mm
6. Layout: Left or right hand machine
Main Parts:
* Cylinder part: two sets cylinder mould;
* Dryer part: two sets dryer can;
* Calender one set;
* Winding machine one set.
Main Equipment
| No. | Name | Function |
| 1 | Stainless steel cylinder mold | Extract the pulp fiber to felt |
| 2 | Alloy dryer cylinder | Dry the wet paper |
| 3 | Double-layer dryer hood | Cover dryer and collect the hot&moist air diffused by dryer |
| 4 | Axial-flow ventilator | Ventilate and pull out the hot&moist air in the exhaust hood |
| 5 | Roots vacuum pump | Provide vacuum force for suction box |
| 6 | Air compressor | Provide compressed air for pneumatic devices |
| 7 | Frequency conversion controlling cabinet | Control the speed of the machine |
| 8 | Vacuum suction box | Absorb water contained in the wet paper |
| 9 | High concentration hydrapulper | Break the waste paper into pulp |
| 10 | High frequency vibrating screen | Separate and remove large impurity in the pulp |
| 11 | Impeller | Stir pulp and keep pulp well-mixed with water |
| 12 | Pressure screen | Getting ride of impurities |
| 13 | Bleacher | Bleach and whiten pulp |
| 14 | Double disc refiner | Grind, refine and fibrillation |
| 15 | Low concentration sand remover | Remove sand and impurities |
| 16 | Pulp pump | Pulp transportation |
| 17 | Electrical operation cabinet | Control machine operation |
| 18 | Boiler | Provide steam for the drying section |
Our company has over 420 employees. We have passed ISO14001 International Authentication. Our products include paper making machines, parts and paper processing machines such as kraft paper machines, tissue paper machines, cultural paper machines, fiber separators, hydrapulpers, rewinders, napkin folders, tissue slitters and so on. They have been exported to more than 8 countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying on advanced technologies, sincere services and inexpensive products of high quality, we have won the recognition of international markets and clients.
Technical Advantage
1.Experienced producing team
2.Advanced technological strength
Product Advantage
1.Through the international authentication
2.The same material the most preferential price
3.A lot of varieties for the customer to choose
Service Advantage
1.Technical consultation
2.Project evaluation
3.Detailed design of factory
4.Installing and testing the whole production line
5.Training engineers and workers
6.Supplying spare parts for long time
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines and so on. Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers’ consistent affirmations.
Q: 1.What information do you need,if i need to get a quotation from you?
A: Output paper type;Capacity(tons/24hours);Output paper weight(gram/m2);Raw material
Q: 2.How long is guarantee period for paper making machine?
A: 12 months after formal operational
Q: 3.What is the delivery time if we make a order from you?
A: Usually,the delivery time for smaller machines is 30-45 days
after receiving deposit,but for bigger machines,it will be longer
to make sure the equipment quality.
Q:4.What is your payment terms?
A: (1). T/T(telegraphic transfer)30% as deposit,and 70% balance paid before shipment.
(2). 30%T/T + 70%L/C at sight.
(3). 100%L/C at sight.
Q: 5.How is the quality of your equipment?
A: (1). We are manufacturer, specializing in producing all kinds of Pulping Machine & Paper
Machine & Environmental Protection equipment for more than 40 years, competitive
with good quality.
(2). We have a technician team of engineers and experts.They mainly research the advanced
paper making technology,to make sure our machines’ design are newest.
(3). The machines will be pre-installed at workshop before delivery.
(4). All of our machines has audited the certificate of ISO
Q: 6.Why your price is higher than other similar supplier?
A: Different quality,different price.Our price is matched with our high quality.Compared with to her suppliers based on the same quality,our price is lower.But anyway,to show our sincerity, we will give you some discount.
Q: 7.Can we visit your factory and the running machine has installed in China?
A: Welcome to visit our factory.You can check our production ability,processing ability,check out facilities and running paper production line. What is more,you can discuss with engineers
directly,and learn the machines well.
