New Model A4 Paper Making Machine, Paper Production Machinery Price
I. Technial data and main parts:
1.Wire section |
Dewater initially and form even wet paper |
2.Press part |
The dryness after press section is about 25-42% |
|
3.Drying part
|
The dryness after drying section is 92-95%. This section consists of several groups dryer cylinders. There is a gas hood to prevent steam evaporating. |
4.Winding part |
Cylinder type winding machine 1 set, Rewinding machine 1 set |
5.Driving control part |
AC frequency conversion speed, section drive |
6.finished product |
Corrugate paper to make carton box |
II.Functions of Main Equipments
| 1 | Stainless steel cylinder mold | Extract the pulp fiber to felt |
| 2 | Alloy dyer cylinder | Dry the wet paper |
| 3 | Exhaust hood of dryer cylinder | To cover the dryer and collect the hot & moist air |
| 4 | Φ600 Axial-flow ventilator | To ventilate and pull out the hot & moist air in the exhaust hood |
| 5 | Roots vacuum pump | To provide the vacuum force for the suction box |
| 6 | Vacuum suction box | To absorb the water in the wet paper |
| 7 | Air compressor | To provide the compressed air for the pneumatic device |
| 8 |
Frequency conversion controlling cabinet |
To control the running speed of the machine |
| 9 | 3m3 High concentration hydra-pulper | break the recycle paper into pulp |
| 10 | 1.8m2 High frequency vibrating screen | To separate and remove the small impurity in the pulp |
| 11 | Φ700mm impeller | To stir the pulp and make sure the pulp and water mixed well |
| 12 | 0.5m2 pressure screen (Slotted screen) | To make the pulp more finer |
| 13 | 35m3 Bleacher (include drive part) | To whiten the pulp through bleaching |
| 14 | Φ330mm pulp refiner | To make the pulp much finer and smoothe |
| 15 | Low concentration sand remover | To remove the sand and impurity in the water and pulp |
| 16 | Pulp pump | To provide the pulp for the needed machine |
| 17 | Electrical operation cabinet | To control the machines run or stop |
| 18 | 1T Boiler (burning coal ) | To provide the hot steam for the dryers |
Final paper
Flow Chart of Cylinder-Type A4 Paper Making Machinery:
Zhengzhou Dingchen Machinery Co.Ltd is a company that specializes in manufacturing paper making machines and other related spare parts. Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria, Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers’ consistent affirmations.
Dingchen Machinery workshop
Certification:
We will offer the world-top products service systerm for our clients. Pay attention to the following contents:
1.Factory plant: we provide clients with guidance on factory design, complete line and material purchasing;
2.Repairing guarantee of product: we provide spare parts for machine, permanent payable maintenance programe, and one year maintenance free of charge.And we also will send engineer to buyers' country according to acutal requirments;
3.Follow-up service of product: we will notify you upon the delivery;
4.Customer Document: we have established a data base for all customers since the beginning of production;
5.After complete of construction: we help our customers train foundation equipment operator for free;
6.Error treatment: the customer service department will take action immediately when they receive any call and provide professional repairer to help you solve your problems as soon as possible;
7.Regular feedback:we will visit the customers again to ask for the suggestion to help improve our quality of service to make you satified.
If you have any questions, pls free feel contact us immediatedly, and we are waitting for your inquiry information
