Automatic Culture Paper Making Machine Paper Production Line Machinery

Automatic Culture Paper Making Machine Paper Production Line Machinery photo-1
Automatic Culture Paper Making Machine Paper Production Line Machinery photo-2
Automatic Culture Paper Making Machine Paper Production Line Machinery photo-3
Automatic Culture Paper Making Machine Paper Production Line Machinery photo-4
Automatic Culture Paper Making Machine Paper Production Line Machinery photo-5
US$ 400,000 - 600,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, cultural paper machine
Processing Type:
Pulp Molding Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, cultural paper machine
Processing Type Pulp Molding Machine
Place of Origin Henan, China
Brand Name Dingchen
Model Number 1880mm
Voltage 380v etc.
Power(W) up the machine
Dimension(L*W*H) up the machine
Weight up the machine
Certification Other, ISO9001:2008
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

  Automatic Culture Paper Making Machine Paper Production Line Machinery

Product Description

Main products:

Automatic Culture Paper Making Machine Paper Production Line Machinery

Technical parameter:

1. Raw material: waste paper, pure wood pulp

2. Output paper:Cultural paper, writing paper, newspaper

3. Output paper weight:40-80gsm

4. Net paper width:2000 mm

5. Copper cylinder width: 2400mm

6. Capacity: 10-12 T per D

7. Working speed: 50-100 m per min

8. Rail space: 2900mm

9. Drive way: Alternating current frequency conversion adjustable speed, section drive.

Flow chart of paper making:

Automatic Culture Paper Making Machine Paper Production Line Machinery

Main equipment structure:

Cylinder section:stainless steel mesh sets;couch roll 3 sets; reverse roll 1 set;

Press section: natural marble roll 2 set

Dryer section: alloy dryer can 6 sets



All equipments:

NO

Equipments

Qty(set)

1

1880 multi-cylinder printing paper machine

1

2

Size press

1

3

Dryer can exhaust hood

2

4

850 Axial ventilator

2

5

SK-20 Water circle vacuum pump

1

6

Suction box

6

7

1880mmWinding machine

1

8

Three roll calendar

1

9

1880mmRewinding machine

1

10

5m3High consistency hydrapulper

2

11

1.2 m2 Inflow pressure screen

2

12

2 m2Highfrequency screen

2

13

606 Desander 10 pcs

1

14

IS250-200A Desander pump

1

15

1.6 m2 Centrifugal screen

2

16

450 double disc refiner

2

17

750 Thruster

6

18

Pulp pump-100

8

19

Pulp pump-150

4

20

Frequency conversion control cubicle

1

21

Air pump cabinet

1

22

Work table

1

23

2T coal fire boiler

1

Automatic Culture Paper Making Machine Paper Production Line Machinery

Automatic Culture Paper Making Machine Paper Production Line Machinery

Automatic Culture Paper Making Machine Paper Production Line Machinery

Automatic Culture Paper Making Machine Paper Production Line Machinery

Picture of paper machine manufacturing:

Automatic Culture Paper Making Machine Paper Production Line MachineryAutomatic Culture Paper Making Machine Paper Production Line Machinery

Certifications
Automatic Culture Paper Making Machine Paper Production Line Machinery



Packaging & Shipping

Picture of packaging and loading: Automatic Culture Paper Making Machine Paper Production Line Machinery

Automatic Culture Paper Making Machine Paper Production Line Machinery

Clients visiting our factory:Automatic Culture Paper Making Machine Paper Production Line Machinery

Our Services

Perfect service:

· Highly inspecting equipments in every working procedure, quality comes first;

· Fast & Safe Delivery; mulity-cylinder;

· Assisting our clients for foundation construction of equipments;

· Dispatching engineers to install and debug equipments;

· Training the first-line operators on site;

· Regularly visit clients to solve production problems;

· Providing life-long maintenance service;

· Providing technical exchanging.





Company Information
We are the MANUFACTURER of high quality machines with competitive price! Such as toilet/

tissue paper machine, cultural paper machine, newspaper machine, craft/kraft paper machine,

corrugated paper machine, etc.



Any questions, please do not hesitate to contact me. Thank you!
