2015 newsprint paper/ a4 paper notebook making machine
I. Technical parameter:
1. Raw material: waste paper
2. Output paper: news paper,office paper, writing and printing paper
3. Output paper weight: 60-80g/m2
4. Net paper width: 2400mm
5. Wire width: 2950mm
6. Capacity: 30 tons/day
7. Working speed: 120-140 m/min
8. Design speed: 200m/min
9. Rail gauge: 3400mm
10.Drive way: A/C converter speed control, section drive.
II. Main structure for paper making machine
1.Wire part
2. Vacuum de-watering part
3. Press part
( In this part, include 2 groups of press part, each part includes one set of natural
marble roll and one set of rubber roll )
4. Dryer part
( In this part, includes 18 sets of dryer cylinders, arrayed in the order of 12 + sizing part + 6)
5. Sizing part
6. Calender part
7. QCS system
8. Winding & rewinding part
9. Driving and controlling part
10. Air compressing system
11.Hot steam recycled system
III. Main equipment list for paper production line
No |
Item and description |
1 |
Closed type head box |
2 |
Forming table for wire |
3 |
hydrofoil box |
4 |
Vacuum suction box |
5 |
alloy dryer cylinder |
6 |
Semi-closed dryer hoods |
7 |
Φ800 axial-flow ventilator |
8 |
Sizing machine |
9 |
2m3 Screw type air compressor |
10 |
2400mm 3 rolls calendering machine |
11 |
2400mm horizontal pneumatic reel |
12 |
2400mm rewinding machine |
13 |
Frequency conversion controlling Cabinet |
14 |
Paper scanner |
15 |
8m conveyor |
16 |
5m3 high consistency hydra-pulper |
17 |
high consistency sand remover |
18 |
High-speed pulp washer |
19 |
0.6m2 Pressure screen |
20 |
1.8m2 Vibrating screen |
21 |
606 sand remover |
22 |
Φ450mm double-disc pulp refiner |
23 |
1.2m2 Pressure screen |
24 |
6T boiler |
25 |
Electrical operating cabinet |
Flow chart
Raw material
The A4 paper making machine
Fourdrinier
Winding Machine
Low consistency sand remover
Paper roll
Zhengzhou Dingchen Machinery Co.Ltd is a company that specializes in manufacturing paper making machines and other related spare parts. Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria, Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers’ consistent affirmations.
• Provide comprehensive shot-peening and shot blasting solution
• 20 years experienced engineers provide best proposal for your need.
• Customized design available
• Oversea engineer service avaliable
• To aim to save your cost and improve efficiency
• Offer OEM service.
• One year warranty for machine
• English manual and Video CD for manchine using and maintance.
• Company enjoys high reputation and favorable comments for quality products, good service, and faithful management in past twenty years
If you have any questions, pls free feel contact us immediatedly, and we are waitting for your inquiry information
