1092mm Double Cylinder and Double Dryer Office Notebook Paper Making Machine
Basic Information of Paper Making:
The raw materials of paper production line range from waste paper, virgin pulp, wood pulp board, wheat straw, rice straw, sugarcane bagasse, cotton linter, cotton stalk, reed, for the purpose of making best quality paper. And the raw material could be determined as per customers' needs for the kind of paper they want. Furthermore, the fininshed product of the paper machine is paper roll and paper sheet. Finally, you can obtain the final product you intend to purchase with the paper converting machines.
The paper making machine is composed of the following parts:
1 pulp making production line
2 sizing press part
3 paper making production line
4 paper cutting and packing part
5 boiler
6 hot steam recylcing part
7 spare parts
Technical Parameters:
1.Raw material: wood pulp, waste paper
2.Output paper style: A4 paper
3.Capacity: 4T/D;
4.Output paper weight: 80-140g/m2;
5.Net paper width: 1200mm;
6.Width of cylinder: 1450mm
7.Rail gauge:1800mm;
8.Drive way: AC inverter speed adjusting, sectional drive
Flow Chart of Cultural Office Notebook Paper Machine:
Main Structures of Model 1092mm:
1 Wire part: stainless steel cylinder mold (2 sets), couch roll (2 sets), return roll(1 set), which are coated by rubber.
2 Press part; natural marble roll(1set), rubber roll (1 set), pneumatic loading device.
3 Dryer part: alloy dry can (2 sets), touch roll (1 set), which is coated by rubber, pneumatic loading device
4 Calendering part: calender with 3 rolls (1 set)
5 Winding part: 1092mm horizontal pneumatic winding machine (1 set)
5 Rewinding part: Upper-feeding frame type rewinding machine (1 set)
Equipment List:
No. |
Item |
1 |
1092mm cultural paper/writing paper making machine |
2 |
dryer hood |
3 |
axial-flow ventilator |
4 |
15 roots vacuum pump |
5 |
suction box |
6 |
frequency conversion controlling cabinet |
7 |
calender (3 rolls) |
8 |
1092mm winding machine |
9 |
1092mm rewinding machine |
10 |
2T boiler (burning gas) |
11 |
hydra-pulper |
12 |
high frequency vibration screen |
13 |
bleacher |
14 |
double-disc pulp refiner |
15 |
centrifugal screen |
16 |
impeller |
17 |
pressure screen for wire part |
18 |
sand remover |
19 |
pulp pump |
20 |
electric operation cabinet |
Pulp Making Equipment:
Pre-sales services:
1) Comprehensive technical consultation services;
2) Proposing the most suitable scheme and equipment for our clients;
3) Designing and formulating the satisfactory products as per the customers' needs;
4) Training periodically high qualified service technician.
5) Adopting all-around computer aided design (CAD) to design the whole production line.
6) Providing turn-key projects as follows: production design,equipment manufacture, installation and adjustment, technical service, confirmation of product.
7) Complete sets machine will be pre-installed and tested to confirm that the machine are in good condition before delivery.
8) On time delivery.
After-sales services:
1) Fast & Safe Delivery;
2) Assisting our clients for foundation construction of equipments;
3) Dispatching engineers to install and debug equipments;
4) Training the first-line operators on site;
5) Providing life-long maintenance service;
6) Providing technical exchanging;
7) Arranging technicians to install and test the machine for you and training your workers;
8) One year guarantee time after running of the machine;
9) Supply you spare parts at a competitive price for a long time.
Real Installation Pictures:
We are the professional Chinese manufacturer in the field of paper making machine, our products covers pulp making equipment, toilet paper machine, kraft paper machine, corrugated paper machine, A4 paper machine, paper coating paper and paper deep processing machine the related spare parts.
We are able to design and work out the production line that meet customers' needs.
So, welcome to visit our factory to have a better understanding of our company and the products.
Contact person: Grace Guo Skype: graceguo15
Mobile: 0086-15903665291
