2200 Multi-cylinder mould and Multi-dryer can coated paper machine
(I).Technical parameter:
Raw material: Waste paper and pure wood pulp
Output paper: Duplex paper
Weight: 200-400g/m2;
Capacity: 20T/D
Net paper width: 2200mm
Wire width: 2450mm
Rail gauge: 2800mm
Drive way: speed adjustment in AC frequency &processing transmission
Work speed: 17-35 m/min
(II). Main frame of equipments:
1.Cylinder part: stainless steel plate style cylinder mould 5 pcs,
part: rubber roll 2pcs, pneumatic loaded device.
3.Dryer part: dryer can 10 pcs, arrangement: 6+ sizing machine +4, it is equipped with dryer felt device.
4.Reeling part: mm reeling machine
5.Rewinder part: rewinder machine
Machine list of paper making part: | ||
No | ||
1 |
Equipments |
Qty (set) |
2 |
2200mm multi-dryer can multi-cylinder mould paper machine |
1 |
3 |
Exhaust hood of dryer group |
1 |
4 |
Axial flow fan |
2 |
5 |
Style 15 roots pump |
1 |
6 |
Suction box |
2 |
7 |
2200mm reeling machine |
1 |
8 |
2200mm rewinder |
1 |
9 |
AC frequency controller |
1 |
10 |
Working table |
1 |
11 |
Air pump |
1 |
12 |
4T boiler |
1 |
