Best Price Chinese Manufactured Toilet/Tissue Paper Deep Processing Machinery

standard export package

 Best Price Chinese Manufactured Toilet /Tissue Paper Deep Processing Machinery

Description of Toilet/Tissue Paper Deep Processing Machinery:

The toilet/tissue paper deep processing machinery consists of perforating, embossing rewinder, paper roll cutter and plastic bag sealing machine to get the requested finished product of small paper roll.

Specifications of Perforating, Embossing Rewinder:

It is designed to make the jumbo roll paper to small diameter paper roll with perforating and embossing

Raw Material of Jumbo Paper Roll:

Specifications of Paper Roll Cutter:

Specifications of Plastic Bag Sealing Machine:

The Production Process of Paper Deep Processing Machinery:

Paper Tube Core Machine is necessary for Making the Paper Roll with Tube:

Specifications of Paper Tube Core Machine:

Other Deep Processing Machinery for Making Napkin/Serviette Paper:

Related Toilet Tissue PaperJumbo Roll Making Production Line for Model 1880mm:

1880mm 5TPD Toilet Paper Roll Making Machine to make Facial Paper/Napkin

Tissue Paper/Kitchen Paper

Technical Parameters:

1.Raw materials: waste paper,virgin pulp

2.Output paper: high and middle class napkin paper,toilet paper , tissue paper

3.Output paper weight: 13-30g/m2

4.Capacity: 5 tons per day

5.Net paper width: 2000mm

6.Wire width: 2300mm

7.Working speed: 60-120m/min

8.Designing speed: 180m/min

9.Rail gauge: 2800mm

10.Drive way: Alternating current frequency converter speed control, sectional drive.

11.Layout type:left or right hand machine.

Main Structure for the Napkin Paper Making Machine:

1 .Cylinder mold part:  one set of stainless steel cylinder molde(1500mm×2300mm×2800mm),  one set of couch roll (450mm×2300mm×2800mm ) which is coated by rubber,  one set of stainless steel cylinder vat.

2. Dryer part: one set of alloy dryer cylinder(2500mm×2300mm×2800mm) , one set of touch roll(550mm×2300mm×2800mm) which is coated by rubber, pneumatic pressure device,  and the dryer cylinder is also equipped with  2 sets of scraper knife and one set of  double-layer dryer hood.

3. Winding part: one set of winding cylinder (900mm×2300mm×2800mm) ,wind paper on the sweat cylinder.

4. Paper converting section: one set of 1880mm rewinding machine with perforating and embossing  1set, 1 set of paper cutter and plastic bag sealing machine respectively.

 Paper Making Machinery:

We are the professional Chinese manufacturer in the field of paper making machine,  our products covers pulp making equipment, toilet paper machine, kraft paper machine, corrugated paper machine, A4 paper machine, paper coating paper and the related spare parts.

We are able to design and work out the production line that meet customers' needs.

So, welcome to visit our factory and I'm loking forward to establish a long-term cooperation with you!
