Henan Toilet Tissue Paper Cutter Cutting Machine with High Quality
Introduction of the machine:
This machine is the equipment for roll Toilet Paper and Kitchen Towel, it is the supporting equipment for rewinding and perforated toilet paper machine. The main function is to cut the rewinded big toilet paper into various kinds of standard small rolls. It features stable operation and high production efficiency.
Main Technical Parameters:
Paper Roll Cutting Machine
| |
Model | 3750(Band Saw) |
Max diameter of base paper roll | 200mm |
Blade length | 3750mm |
Blade width | 40mm |
Wheel diameter | 440mm |
Working speed | 160-240m/min |
Processing capacity | 30-60rolls/min |
power | 1.1kw |
Dimension (L×W×H) | 1170×780×1800mm |
Weight | 460kg |
Brief Introduction of Dingchen Company:
We are the MANUFACTURER of high quality paper machines with competitive price!
Such as toilet/tissue paper machine, cultural paper machine, newspaper machine,
craft/kraft paper machine, corrugated paper machine, etc, as well as the pulp making equipments(D-type hydrapulper, vibrating screen, pressure screen, pulp pump) and paper converting machine.
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers’ consistent affirmations.
Flow Chart of Paper Converting Section:
Related Converting Machines:
1 1880mm rewinding, perforating and embossing machine
| model | 1880mm paper rewinding machine |
| raw material width | 2000mm |
| finished roll diameter | 70-140mm(adjustable) |
| paper core diameter | 76.5mm |
| layer | 1-3 layers |
| control | PLC |
| speed | 140-180m/min |
2 Plastic bag sealing machine
| power | 220V/50HZ |
| length of sealing | 500mm |
| width of sealing | 6mm |
Paper making production lines we can provide
Waste paper pulp machine production line
Corrugated box production line
Corrugated paper making production line
Fluting paper pulp making production line
Coated White Board Paper production line
Testliner paper making production line
Paper plate making production line
Tissue paper making production line
Toilet paper making machine line
kraft paper making machine line
Boxboard paper machine line
Paper coating machine line
Napkin paper machine line
OCC line
Zhengzhou Dingchen Machinery Co.,Ltd
ADD: 3F, No.38 Building,No.1 Cuizhu Street, High-tech zone, Zhengzhou City, Henan Province,China
Contact person: Grace Guo
Tel:0086-371-86099805-8008
Fax:0086-371-86099201
Mobile:086-15903665291
Skype: graceguo15
Website:
http://dingchenmachinery.en.china.cn
http;//
Welcome to contact us to get more details !
We can design the machine according to your request.
