Permanent Magnet Generator Alternator,generator Alternator Type Water Turbine Generator
US$ 11,910 - 45,240
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
RICHUAN
Model Number:
RCVA-HAWT-30000
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Farm Use Easy Installation 30kw Wind Turbine SystemUS$ 15,900 - 35,200MOQ: 1 Set -
30kw New Design Magnetic Generator Free Energy, CE Approved Vertical Axis Wind Turbine Price for SaleNegotiableMOQ: 1 Piece
-
2015 China New ce Approved Vertical Wind Turbine 30kwUS$ 45,000 - 53,000MOQ: 1 Set
-
Hot Sale!!! 2015 Newest 30kw/30000w Vertical Axis Wind Turbine Generator for SaleNegotiableMOQ: 1 Piece
-
Richuan 30kw Vertical Axis Prices of Generators in South AfricaUS$ 47,660 - 54,500MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
RICHUAN
Model Number
RCVA-HAWT-30000
Type
Wind Power Generator
Specifications
30KW Pitch Controlled Wind GeneratorSecurity, stability, easy to start up
Gearless, Permanent Magnetic Generator
Hydrauli
Richuan brand permanent magnet generator alternator,generator alternator Type Water Turbine Generator
The 30KW Pitch Controlled Wind Generatoradopts rotating speed of generator to control the angle changing of blade, as the changing of rotating speed, the blade twist the angle accordingly to change the aerodynamic characteristics of blade, controlling the rotating speed of the wind turbine generator, and changing the internal mechanism to get displacement , realizing generator constant power output
Specification of 30kw pich controlled wind generator
technical specification
| Generator | |
| Rated power | 30000w |
| Max power | 35000w |
| Start-up wind speed | 2.5m/s |
| Rated wind speed | 11m/s |
| Rated torque | 2864.7NM |
| Working wind speed | 3-25m/s |
| Rotor diameter | 12.5m |
| Security wind speed | 45m/s |
| Rated RPM | 100 |
| Rated voltage | 360v |
| Generator type | permanent magnet |
| Working temperature | -50-120°c |
| Speed regulation and protection | yawing + electromagnetic brake + manual brake |
| Blades and tower | |
| Blade material | reinforced fiber glass |
| Blade weight | 120kg/pcs |
| Blade weght | 6m |
| Tower type | Free standing tower |
| Tower heght | 15m |
| Others | |
| Weight of top section | 1130kg |
| Controller rated voltage | 360v |
| Suggested battery bcapacity | 12V150AH 60pcs |
Feature of 30kw pitch controlled wind generator
1.Advanced pitch-controlled technology, enable the turbine blades to catch the best angle for wind power utilization
2.Easy start-up behavior and keep constant power output under gust, wide working wind speed from 3m/s to 35m/s
3.Multi-protection methods ensure system in high reliability and safety during high wind speed operation (yawing + electromagnetic brake + pitch controlled + manual brake)
4. Cast steel body with anti-corrosion treatment for working well in harsh environment
5. Direct drive, gearless, maintenance-free permanent magnet generator
Advantages of 30kw pitch controlled wind generator
1. running safety in huge wind speed condition.
2. stable output voltage good for grid tie system
3. protecting well wind turbine, controller and inverter.
4. more efficiency than normal wind turbine.
Application of 30kw pitch controlled wind generator
