Help CenterCE Approved Richuan 300w Mini Vertical Axis Permanent Magnet Wind Turbine Generator
Related Products
-
CE Approved Permanent Magnet Wind Turbine 300w Vertical Wind GeneratorUS$ 775 - 1,400MOQ: 1 Set -
2015 New Design Wind Turbine System 300w Wind Generator for SaleUS$ 775 - 1,400MOQ: 1 Set
-
New Hot Products 5kw Permanent Magnet Generator of 2015US$ 440 - 868MOQ: 1 Set
-
2015 New 5kw Low Rpm Permanent Magent Generator,selling Magnetic Motor With Wind TurbineUS$ 440 - 868MOQ: 1 Set
-
New Vertical Wind Generator China Wind Vertical Turbine 300wUS$ 650 - 1,300MOQ: 1 Set
Product performance
1. High power generation efficiency of darrieus - savonius - type blade of the leaf high torque distribution, research and development of high performance blade rotor, hits the low wind speed start of the operation, high efficiency continuous power generation, low noise requirements and to adapt to change the frequency of wind environment.
2.Using direct - drive permanent magnet synchronous generator, low starting torque increase of the
electric power conversion efficiency of wind power, does not need by using the growth, reducing the mechanical losses.
3. Maximum power tracking of the use of advanced features, is generating capacity and load achieve the best match. Battery storage, discharge function can overcome the disadvantages of wind energy instability.Can be used go with the commercial power supply, increase power supply stability.
Product advantages
1 Advanced aerodynamic design
2 Unique waterproof, moisture-proof, anti-dust, anti-salt spray design
3 Low noise design
4 High-strength, corrosion-resistant special glass fiber reinforced plastic material
5 One-year warranty
Technical parameters:
| Power | 300W |
| Type of generator | Permanent-magnet 24vA.C. |
| Rotor diameter: | 1.2m |
| Blade Material: | FRP (Fiber glass reinforced*5) |
| Rated rotor speed | 150r/min |
| Rated speed | 10m/s |
| Rated Power | 300W |
| Max Power | 450w |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 6m |
| Top quality except tower | 75kg |
| Output controller system | Controller , Inverter |
