Disc Coreless PMG ! 300w 600w 1kw 2kw generator for Vertical axis wind generator
vertical axis wind turbine Products advantages:
1.Low starting torque, low start wind speed.
2.Low speed permanent magnet generator.
3.No vibration & low noise.
4.All of our products confirm to CE .
5.Reliable wind power system by multifunction controller.
6.PWM constant voltage recharge function provides stable output.
7.Variable pitch system, power optimization, higher efficient transformation from wind power into electricity.
8.On-grid or Off-grid wind power system optional.
9.2-year warranty for generator and 18-20 years service life.
10.Electronic brake and manual brake, optional.
11.High efficiency and Low mechanical resistance energy loss.
12.Special sealed wind turbines, moisture, sand and water proof.
Type of generator |
permanent magnet 3-phase |
Stator |
silicon settle sheet |
Magnet steel |
NdFeB |
Magnet material |
38SH |
Wire package |
copper wire |
Rotation speed |
120r/min |
Rated power |
1000W |
Protection level |
IP54 |
Service life |
More than 16 years |
Blades length |
2.0m |
Blades weight |
7kg/pc |
Start up wind speed |
3m/s |
Rated wind speed |
10m/s |
Operating wind speed |
3-25m/s |
weight of top section |
100kg |
Generator |
Type of generator: permanent magnet 3-phase |
Stator: silicon settle sheet | |
Magnet steel: NdFeB | |
Magnet material: 38SH | |
Rated rotated speed: 120r/min | |
Rated power: 1000W | |
Max power: 1500W | |
Output voltage: DC48V/AC220V | |
BLADES |
Material of blades: high efficiency aluminium alloy material, ultraviolet prevention rosin, plus unidirectional high strength glass fiber, modernization craft vacuum cast technique synthesis. |
number of blade: 5pcs | |
Rotor diameter: 1.8m | |
Start-up wind speed: 1.5m/s | |
Rated wind speed: 8m/s | |
Work wind speed: 3-25m/s | |
Tower |
Tower type: guy cable tower |
Height of pole: 6m | |
Material: Q235 steel | |
Surface treatment: painting against decaying | |
Other parameters |
Certificate: CE |
Suggested battery type : 12V150AH 4pcs | |
Speed regulation: Leaning tail + electric brake | |
Service life: 18-20years |
Vertical axis wind turbine from 300w to 50kw! More details please contact us.
