Vertical Axis Wind Turbine 10kw for Industrial Use

Name: Vertical Axis Wind Turbine 10kw for Industrial Use
Brand: RICHUAN
SKU: 102945587
Availability: InStock

US$ 18,000 - 21,800 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

RICHUAN

Model Number:

RCVA-10KW

Qingdao Richuan Precision Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name RICHUAN

Model Number RCVA-10KW

Type Generator

Electricity Generator Type Wind Power

Output Voltage (V) 240

vertical axis wind turbine 10kw for industrial use

Products advantages:

1.Low starting torque, low start wind speed.

2.Low speed permanent magnet generator.

3.No vibration & low noise.

4.All of our products confirm to CE .

5.Reliable wind power system by multifunction controller.

6.PWM constant voltage recharge function provides stable output.

7.Variable pitch system, power optimization, higher efficient transformation from wind power into electricity.

8.On-grid or Off-grid wind power system optional.

9.2-year warranty for generator and 18-20 years service life.

10.Electronic brake and manual brake, optional.

11.High efficiency and Low mechanical resistance energy loss.

12.Special sealed wind turbines, moisture, sand and water proof.

Generator	Type of generator: permanent magnet 3-phase
	Stator: silicon settle sheet
	Magnet steel: NdFeB
	Magnet material: 38SH
	Rated rotated speed: 20r/min
	Rated power: 10000W
	Max power: 12000W
	Output voltage: DC240V/AC220V
BLADES	Material of blades: high efficiency FRP material, ultraviolet prevention rosin, plus unidirectional high strength glass fiber, modernization craft vacuum cast technique synthesis.
	number of blade: 5pcs
	Rotor diameter: 7.5m
	Start-up wind speed: 3m/s
	Rated wind speed: 12m/s
	Work wind speed: 3-25m/s
Tower	Tower type: free stand tower
	Height of pole: 12m
	Material: Q235 steel
	Surface treatment: painting against decaying
Other parameters	Certificate: CE
	Suggested battery type : 12V200AH 20pcs
	Speed regulation: electric brake
	Service life: 18-20years
