Help Center50KW Low RPM, PMG (Permanent Magnet Generator)
Related Products
-
CE Approved Richuan 1kw 2kw 3kw 5kw 10kw Wind up Dynamo GeneratorUS$ 170 - 60,000MOQ: 3 Sets -
2015 Disc Coreless PMG ! Richuan 1KW Vertical Wind Turbine Permanent Magnet GeneratorUS$ 450 - 750MOQ: 10 Sets
-
2015 Hot Sale Richuan Permanent Magnetic Generator ! AC 3-Phase Mini Wind Power Generator 300wUS$ 175 - 400MOQ: 2 Sets
-
2015 Disc Coreless PMG ! 1kw Axial Flux Permanent Magnet Generator for SaleUS$ 450 - 750MOQ: 10 Sets
-
2015 Richuan Permanent Magnet Generator 3 Phase 300w to 200kw Wind GeneratorUS$ 200 - 30,000MOQ: 1 Set
Product performance:
Technical Details | |
Rated Power(KW): |
50 |
Rated Speed(RPM): |
50 (Customized) |
Rated Torque(N*M): |
9549 |
Rated Voltage(V): |
360 (Customized) |
Rated Current(A): |
80 |
Insulation Class: |
F |
Efficiency |
>92% |
PMG Collocation: |
Y Connection,Three Phase Three Wires, Alternator |
Service Life: |
More Than20 years |
Working Environment |
-50 Centigrade——60Centigrade |
Speed Range |
0-70rpm |
Mechanical Details | |
Mounting Means |
Vertical or Horizontal |
Weight(Kg) |
2185 |
Start Torque(<N*M) |
143 |
Material Details | |
Shaft Material |
40Cr Steel with quenching and tempering Treatment |
Bearing |
C&U or for your order |
Shell Material |
Steel |
Winding Temperature Class |
150Centigrade |
Permanent Magnet Material |
Rare Earth NdFeB |
Permanent Magnet Material Temperature Class |
150Centigrade |
Core |
High Grade Cold Rolling Silicon Sheet 50WW470 |
Protection Grade |
IP54 |
Product advantages:
1.Unique waterproof, moisture-proof, anti-dust, anti-salt spray design
2.Low noise design
3.low rpm
4.Rpm & Voltage can be customized
5.One-year warranty
Transport and services:
Recommended mode of transport: Freight by sea
Because it is very heavy.
