Help CenterChina Professional Steel Wire Puller/Waste Radial Tire Wire Drawer/Steel Wire Puller
Related Products
-
Model LS-800 Type Waste Tire /Tyre Wire DrawerUS$ 15,000 - 21,199MOQ: 1 Set -
Model LS-1200 Type Waste Tire Shredder Recycling Line-Waste Tire /Tyre Wire DrawerUS$ 15,000 - 21,199MOQ: 1 Set
-
Double Hook Waste Tire /Tyre Wire Drawer For Waste Tire Shredder Recycling LineUS$ 10,000 - 20,000MOQ: 1 Set
-
Double Hook Steel Wire Puller/Tire Wire PullerUS$ 16,000 - 22,000MOQ: 1 Set
-
Double Hook Tire Wire DebeaderUS$ 15,000 - 21,199MOQ: 1 Set
Specifications
1.11Years'experience2Brand pulverizer,shredder,sifter,separator
3Lifetime warranty
4.Lowest price
5.ISO9001SGSCertification
China Professional Steel Wire Puller/Waste Radial Tire Wire Puller/Steel Wire Puller
We produce rough crusher, shredder,automatic tire cutter,bead-wire drawing machine,tire splitting machine,separator,screener,conveyer and all kinds of waste tire recycling machines,and with the strong technology we can accept custom made!
Tel: +86-510-66200163
cell phone: +86-151-6165-5901
Contact:Mandy Van
Skype:mandy20120903
China Expert on Waste Rubber Pulverization
Background: Waste tyre is solid waste in Britain, Canada or other developed countries, so got it with lower prices, may have a big wealth, because waste tyre really is a treasure for its broad use.
In recent years, with the development of industry, waste tyre can play an important role , whether bias tyre or radial tyre, its main component is rubber, metal, textile,, these materials can be recycled. With radial tyre for example, 25% of steel wire can be processed into steel grit, as shipyard derusting, every tons of price is RMB5000, also can make steel ball for cement mill every tons of price is RMB6000. And 75% of rubber mixture, can be processed into fine glue powder, every tons of price is RMB3000, for other hand this waste rubber can be processed into reclaimed rubber, every tons of price is RMB4000, these material has been widely used in rubber industry, building materials industry and plastics, coatings, highway, etc. So waste tyre isn't junk but the recycling of renewable resources.
Main Processing:
1.steel wire drawer: separate the wire in the tyre.
2.whole tyre crusher: crush the tyre to 30-80cm chips
3.rubbing/cutting machine: coarse crushing, fine milling, separating steel wire etc .
4.rubber powder screener: grading the crude fibre and rubber powder.
5.Belt Iron separator: mainly applied for separating the iron materials from the rubber particles.
6.Magnetic roller Iron separator: can be effectively used for separating small iron powder.
7.rubber fiber separator: used in separating the fine fluff fibre mixed in rubber powder.
8. rubber fine miller: fine grind the rubber granule to 5-100mesh.
China Professional Steel Wire Puller/Waste Radial Tire Wire Puller/Steel Wire Puller
Application:
This machine is used for drawing out the steel wire from the radial tire,it's the fist status to recycle the waste tire,can save much time and improve the efficience of the rear operation.
Structure & Principle:
The machine consists of the motor, hydraulic system, hook, handle and the body . The basic principle is that the motor drive the hydraulic systems and fuel tanks, and the hook is connected to the cylinder trolley. Due to the reciprocating movement of the oil pump and the cylinder, the machine pulls the tire steel part. The tire steel part and the rubber part are separated by the powerful pull of the cylinder.
Specification:
| Model | Power(kw) | The Max Journey | Matching Tire | Pull(Newton) | Frequency(time/min) | Weight(kg) | Overall Dimension L*W*H (m) | ||
| 800-type | 5.5 | 800-type | 800 | 5 | 1 | 600 | 2*0.5*1 | ||
| 1200-type | 11 | 1200-type | 1200 | 12 | 1.5 | 1200 | 3*0.8*1 | ||
Main Export Markets:
Eastern Europe
North America
Mid East/Africa
Central/South America
Asia
Western Europe
Australasia
Delivery time: 25-35 days after receiving 30% deposit.
Service: Provide Installation, maintenance and technical guidance for life.
Guarantee:Quality free for One year,maintainance for lifetime
P.S:The quality guarantee is 12 months after finishing the trial run of machines which has been shipped to the buyer side. If any part (excluding easily damaging parts) is found defective in quality within warranty period, we would like to replace it for free. After warranty, spare parts can be replaced based on favorable price.
