UHF Gate type channel Reader for Library Management
1. Product description
UHF Channel Reader is an advanced UHF tag channel device. It support UHF EPC Gen2(ISO18000-6C), ISO18000-6B tag’s anti-collision and reading-writing dealing. The communication type contain standard RS232, RS485 and TCP/IP, and it can connect with mainframe, controller or other device directly. This device is the ideal choice for open / mass flow check in and attendance.
2. Picture
3. Features
- Ø Comply with EPC CLASS1 G2(ISO18000-6C), ISO18000-6B protocol;
- Ø Frequency: FCC:902~928MHz or CE 865~868MHz (frequency is optional)
- Ø FHSS or fixed frequency transmission
- Ø The max output power is 30dBm (adjustable)
- Ø Built-in infrared motion detection sensor
- Ø Advanced anti-collision algorithm and high identification rate
- Ø Low Power dissipation
- Ø Support RS232, RS485 and TCPIP communication type;
- Ø Built-in buzzer and indicator light;
- Ø Support plug-in camera, large screen and television, realize intuitive monitoring and management
- Ø *Effective distance depends on protocol, antenna, tag and working environment.
- 4. Specification
Items |
|
Color(frame) |
Grey / yellow |
Height1 |
170cm |
Wide2 |
60cm |
Thickness3 |
15cm |
Weight4 |
40kg |
Power |
220/50 V/Hz |
IAC |
160 mA |
Note:
1,2,3: Single antenna’s dimension
4: Single antenna’s weight
5. Contact Detail:
Address |
Yinhe Building, 2008 Xinluo str. High-tech District, Jinan 250101 Shandong Province, China |
Mob |
+8615069005136(Jenny Xu) |
Office |
0531-88118020-833 |
Skype |
sdmwrfid06 |
6. Product detail picture:
