EPC Passive Long Range Reader/warehouse Management Reader

Name: EPC Passive Long Range Reader/warehouse Management Reader
Brand: Hiultra
SKU: 102801247
Availability: InStock

Shandong Mingwah Aohan Smart Tech Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Hiultra

Model Number:

EPC passive long range reader

Payment & Shipping

Payment Methods:

Port of Shipment:

Jinan

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Hiultra

Model Number EPC passive long range reader

Specifications

EPC passive long range reader
1.stable reading distance
2.good quality
3.muti-tag identification
FREE SDK

EPC passive long range reader/warehouse management reader

Why do you choose us?

&15 years experience in RFID field

&Experienced in RFID software and hardware

&Timely delivery, competitive price and free sample for test

1. Brief Description:

EPC passive long range reader/warehouse management reader

1) Built-in circularly polarized antenna

2) ISO18000-6B/6C protocol

3) Read& write function: read range >6m, write range 60% of read range (depend on different tags)

4) Multi-tag identification, single-tag reading, writing, locking and killing.

2.Performance Characteristics:

EPC passive long range reader/warehouse management reader
Model	MS-9601H Middle Distance RFID Reader
Dimensions	240mmX240mmX30mm
Weight	1 Kg
Operating Temp	-20°C to +80°C
Interface	Standard: Viegand26, Viegand 34, RS485, RS232, set by software Optional: WiFi, RJ45
Data Input Interface	One group Trigger Input
Indicator	Buzzer
Power Supply	DC 9V (equipped with power adaptor)
Certificates	FCC CE CCC
RFID Parameters
Frequency Range	Standard ISM 902~928MHz and ISM 865~868MHz for option, can customized other frequency
Protocols	ISO18000-6B, ISO18000-6C (EPC GEN2)
Work Mode	FHSS
RF Power	0 to 30dBm, adjustable by software
Antenna	Build-in 7dBi circularly polarized antenna
Read Range	>6.0m
Read Mode	Timing reading, triggering reading, set by software
Reading Speed	<6ms per 64 bits, set by software
