Features for lab bottom load furnace :
All the hearth material are made by the imported Morgen fiber, and its effect of energy-saving is more that 80% of the old furnace.
Our products have the advantages warming faster 20-40 mins, energy saving, high precision temperature control, heat preservation performance , the microcomputer control, programmable automatic temperature, temperature at furnace wall to such high interest conditions, Widely used in ceramic industry, chemical industry, electronic, metallurgy, new materials, machinery, fire-proof material, building materials, special materials of experiment and production. welcome old and new customers.
1. Operation Temperature: 1700°C/1600°C.
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 50 segments programmable.
We offer OEM service for you!
| Standard Working Temperature: | 1600.C ( continuous ) | |
| Maximum Working Temperature: | 1700.C ( < 3 hrs) [Others degree:1400.C/1700.C/1800.C] | |
| Inside Chamber Size: | 100*100*100mm | |
| Temperature Control: | 31~50 steps programmable and PID automatic control | |
| Heating Rate: | 10~40.C/ min (suggestion:<20.C) | |
| Temperature Accuracy: | +/- 1.C | |
| Working Voltage: | AC 220V Single Phase 60/50 Hz (or according to your requirement) | |
| Furnace structure: | Double shell with fan cooling | |
| Heating Element: | High Quality Mosi2 Heater | |
| Thermocouple: | B type | |
| Standard package included with the furnace: | ||
| Part description | Quantity | |
| Thermal couple: | 1 pc | |
| Stainless steel hook: | 1 pc | |
| Thermal gloves: | 1 pair | |
| Operation manual: | 1 pc | |
| Non-standard size could be made according to your requirement. | ||
| Package: Plastic paper inside, Polyfoam filled, Wooden box outside. | ||
| Payment: L/C T/T, West union, etc. | ||
| Shipping and Delivery: By air, in 15 days after receiving the payment | ||
| Warranty: Our products are warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs. | ||
| Replacement will be shipped to you after photo or other evidence are provided and investigated. | ||
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: L/C T/T, West union,etc.
Shipping and Delivery: by air or sea , in 15 days after receiving the payment
