Help CenterCheapest Price Manual Hot Foil Stamping Die Cutting Machine
Related Products
-
LXML Manual Paper Die Cutting Creasing MachineUS$ 4000.00 - 4000.00MOQ: 1 Set -
RTB The Cheapest Hot Melt Coating MachineNegotiableMOQ: 1 Set
-
WHT350 The Cheapest No-scratch BOPP Tapes Hot Melt Coating & Laminating MachineNegotiableMOQ: 1 Set
-
RTS Label Paper Hot Melt Coating MachineNegotiableMOQ: 1 Set
-
RTS Label Paper Hot Melt Coating MachineNegotiableMOQ: 1 Set
The series of model LXTYMK gilding, cutting & mark pressurized machine is product of new generation with clockwork precision and marked effect. It is used for gilding-printing all kinds of colored electro-chemical aluminum, marking a concave-convex die-cutting pictures, trade mark, advertisement of sample, boxes ,cover of books and new year card, highly decorations and printing materials. It is the optimum equipment for printing, packing, decoration and plastic industries with materials including paper, and cardboard, plastic, leather matters.
It adopts high quality material and high tension of casting
It adopts four-shaft bevel wheel structure with steady operation, great cutting, and low noise.
Sound and layout of its height, great angle of frame.
Electrical system is designed according to IEC standard.
It has three functions for single slitting, successive slitting, and time delay. It can be adjusted.
Safety protection system is reliable.
Concentrated lubricating system.
1. Creasing machine 2.Die Cutting Machine 3.Hot Stamping Machine
Model |
LXTYMK750 |
LXTYMK930LS |
LXTYMK1040LS |
LXTYMK1100LS |
LXTYMK1200LS |
Max.Platen Working Area |
750*520mm |
930*670mm |
1000*720mm |
1100*800mm |
1200*820mm |
Max. Gilding Printing Area |
740*510mm |
930*640mm |
1000*720mm |
1100*800mm |
1200*820mm |
Working Pressure |
150T |
170T |
200T |
220T |
240T |
Foil-delivered Length |
520mm |
640mm |
720mm |
800mm |
820mm |
Foil-delivered Group |
2 group |
3 group |
3 group |
3 group |
3 group |
Working Speed |
25±3time/min |
23±2 time/min |
23±2 time/min |
22±2 time/min |
22±2 time/min |
Main Motor |
2.2kw-6h |
4kw-4h |
4kw-4h |
4kw-6h |
4kw-6h |
Overall Power |
7kw |
13kw |
13kw |
16kw |
16kw |
Total Weight |
2200kg |
3500kg |
3800kg |
4700kg |
5000kg |
Overall Dimension |
1450*1900*1950mm |
1800*1900*2150mm |
1800*1950*2150mm |
2150*2150*2300mm |
2150*2250*2300mm |
