Product Description

Audiovisual System Electric Lcd Lift RS232 Control

DESCRIPTION

BW-LU series electric lcd lift specially designs for high-class conference solutions. With its stable and reliable performance, simple and smart operation, It’s pretty popular in AV conferencing, intelligent office furniture, multimedia education, military command and financial analysis system etc.

With its unique overall functions, it provides an efficient solution and enjoyable experience in conference communication especially for enormous information share like data, image and sound etc. The lcd lift is usually used together with our tabletop sockets to produce unexpected results.

Characteristics

17”, 19”,22”, 24” available, others can be customized
Aluminum oxidation with drawing polishing surface process to make sure smooth and bright panel
Adopting superior gear machine to produce precise gear to ensure stable and reliable lift;
Selecting qualified mute motor with CE CCC marked
Drive sytem: constructed by belt gearing and dual-rack system that highly improve the operation stability and also make very low noise.
Provided with English buttons to control the lift, UP, DOWN, STOP, FORWARD, BACKWARD
Remote control ,manual control and central control;
Circuit Board protection system: Supply power automatically when the monitor lifts up. Power off automatically when lift down to help reduce energy consumption
Adjustable angel of the screen after lifts up.
Equipped with different data interfaces for convenient data access.

Parameters

Item NO.	BW-LU17	BW-LU19	BW-LU22
Style	LCD Lift with monitor	LCD Lift with monitor	Lcd lift with monitor
Products	Monitor+lift+remote control	Monitor+lift+remote control	Monitor+lift+remote control
Panel size	4901604mm	5501604mm	6201904mm
Box size	470150655mm	530150655mm	600175665mm
Panel thickness	4mm	4mm	4mm
Lift mount size	420*80mm	480*80mm	540*105mm
Packing size	578250770mm	650270780mm	720300850mm
N.W	22kg	24kg	28kg
Voltage	110-220v	110-220v	110-220v
Power	20W	20W	20W
Pitch angle	0-15°	0-15°	0-15°
Single trip time	≤20s	≤20s	≤20s
Working Temp.	0-45°	0-45°	0-45°
R.H.	≤80%	≤80%	≤80%
Color	silver/black	silver/black	silver/black
Remote distance	35m	35m	35m
Operation noise	≤30db	≤30db	≤30db
Material	Wiredrawing aluminum alloy	Wiredrawing aluminum alloy	Wiredrawing aluminum alloy
Control way	Touch key-press/Remote control/RS485 central control	Touch key-press/Remote control/RS485 central control	Touch key-press/Remote control/RS485 central control
Running way	double motor with gear drive	double motor with gear drive	double motor with gear drive
Protecting way	protecting finger from nipping	protecting finger from nipping	protecting finger from nipping
Accessory	stator 2pcs screw(5*10mm)4pcs power line 1 pc

Package&Shipping

Electric LCD Lift BW-LU17 package, usually is with standard export cartons:

1pc/ ctn 58*25*77cm

3pcs/wooden case 64*63*73cm

by courier like DHL, FedEx, UPS, TNT, TOLL etc.

by air to any airport around the world

by sea to any port around the world

by trail to inland countries

Service

1. Sample service is available

2. OEM is warmly welcomed

3. Shipment and sample quality tracking.

4. Quick response , enquiry will be repond within 24 hours

5. high qualified after sale service

FAQ

Picture Of Motorized Lcd Lift
