Aluminum Silicate Heat Preservation Blanket Heat Insulation Blanket Ceramic Fiber Protection Blanket

Aluminum Silicate Heat Preservation Blanket Heat Insulation Blanket Ceramic Fiber Protection Blanket thumbnail-1
Aluminum Silicate Heat Preservation Blanket Heat Insulation Blanket Ceramic Fiber Protection Blanket photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Grade:
HA (High Aluminum)
Application:
Liners Of Industrial Furnace, Insulating material of high temperature
Thickness:
20-50mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Grade HA (High Aluminum)
Thickness 20-50mm
Width 610/1220mm
Length 3000/5000mm
Chemical Composition AL2O3≥52%, AL2O3+SiO2≥97%
Working Temperature 1200℃
Fiber Diameter 3μm
Shrinkage (1800 ℉, 3h) <3%
Thermal Conductivity 0.132
Model Number YXTX-422
Brand Name YAOXING
Place of Origin Shandong, China

Specifications

1.Aluminum silicate heat preservation blanket
2.Material:ceramic fiber,glass fiber
3.Working Temp:500C
4.Packing:cartons







Product Description







Technical Index





Classification

Temperature

1050

1260

1400

Code

TXTX-112

TXTX-212

TXTX-312

TXTX-422

TXTX-512

Shrinkage

on

Heating (%)

950°C

×24h

≤-3

1000°C

×24h

≤-3

1100°C

×24h

≤-3

1200°C

×24h

≤-3

1350°C

×24h

≤-3

Theoretical

 Thermal

Conductivity

 (W/m·k)

(128kg/m3)

0.09

(400°C)

0.176

(800°C)

0.09

(400°C)

0.176

(800°C)

0.09

(400°C)

0.176

(800°C)

0.22



(1000°C)

0.132

(600°C)

0.22

(1000°C)

0.76

(600°C)

0.22

(1000°C)

Theoretical

Density

(kg/m3)

64/96/128

Specification

(mm)

7200/5000/3600/3000×610/1220×/20/30/40/50

According to your requirements

Tensile Strength

(Mpa)(128kg/m3)

0.08-0.12

AL2O3(%)

≥44

≥45

≥45

52~55

38~40

ZrO2

-

15~17

AL2O3+SiO2(%)

≥96

≥97

≥99

≥99

—

AL2O3+SiO2+ZrO2(%)

—

—

—

—

≥99

Fe2O3(%)

≤1.2

≤1.0

≤0.2

≤0.2

≤0.2

K2O+Na2O(%)

≤0.5

≤0.5

≤0.2

≤0.2

≤0.2

Package

Plastic Bag Inside, Carton Box Outside

Quality Control System

ISO9001-2000, ISO14001-1996





Characteristic



1.Excellent Chemical Stability

2.Excellent Thermal Stability

3.Excellent Tensile Strength

4.Low Thermal Conductivity

5.Low Heat Storage





Application



1.The material of wall lining and back lining of industrial furnace and the sealing

and insulation material of expanded gaps of furnace wall, furnace door, furnace top lid, etc.

2.Insulating material of high temperature

3.Excellent materials to produce module and folded module
