Help CenterFire Rated Ceramic Fiber Wool Gasket
Related Products
-
Ceramic Fiber Paper Gasket Heat Insulation GasketNegotiableMOQ: 1000 Pieces -
Ceramic Fiber Special-shaped Products Ceramic Fiber Shape ZiboNegotiableMOQ: 100 Cartons
-
Ceraform Sleeves Refractory Ceramic Fiber Shape Ceramic Sealing ShapeNegotiableMOQ: 100 Pieces
-
Thermal Wool Ceraform Sleeve Industrial Furnace Door Sealing Ceramic Fiber Ceramic Fiber GasketNegotiableMOQ: 1000 Pieces
-
High Temperature Ceramic Fiber Paper GasketUS$ 3.39 - 4.58MOQ: 10 Rolls
Specifications
Ceramic Fiber Paper1.Density: 200-220kg/m3
2.Thickness: 0.5~7mm
3.Type: High Aluminum
4.Working temperature:1100C
Description
Zibo Yaoxing is a professional manufacturer of ceramic fiber products for more than 10 years.
Ceramic Fiber Paper is made from ceramic fibers bonded with a low percentage of organic binder;
it has excellent thermal insulation properties and good handling characteristics.
Product Characteristic:
♦Low Heat Storage
♦Low Thermal Conductivity
♦Excellent Thermal Electrical Insulation
♦Excellent Machine-processed Capability
♦Excellent Broken Resistance
♦Excellent Flexibility
♦Low Shot Content
Application Range:
♦Industrial insulating ,sealing and protecting materials
♦Electric and thermal insulation materials for electric industry
♦Insulation materials for instrument-equipment
♦Insulating materials for motor industry
♦Filling materials for expansion slot
♦Insulating materials as the sinter resistance
♦Sealing gasket for molten metal
♦Fireproof materials
Classification Temperature |
1260 |
1400 |
|
Name |
ST Ceramic Fiber Paper |
HZ Ceramic Fiber Paper |
|
Code |
YXTX-236 |
YXTX-336 |
|
Shrinkage on Heating (%) |
1000°C×24h ≤-3 |
1350°C×24h≤-3 |
|
|
Theoretical Thermal Conductivity (W/m·k) |
(200°Caverage) (400°Caverage) (600°Caverage) |
0.075-0.085 0.110-0.121 0.160-0.170 |
|
Organic Content (%) |
≤ 10 |
≤ 8 |
|
Theoretical Density (kg/m3) |
200±15 |
||
Tensile Strength (Mpa) |
≥0.3 |
≥0.2 |
|
Moisture Content(%) |
≤1 |
||
Specification (mm) |
100000/12000×610/1220×0.5/7, According to your requirements |
||
Package |
Plastic Bag Inside, Carton Box Outside |
||
Quality Control System |
ISO9001-2000, ISO14001-1996 |
||
