Help CenterYaoxing 1400C Ceramic Fiber Paper
Related Products
-
1260C 200K Ceramic Fiber Paper Ceramic Fiber Paper for Industrial Equipment Heat Insulation Ceramic Fiber PaperNegotiableMOQ: 200 Rolls -
High Temperature Ceramic Fiber Paper Heat Insulation Ceramic Fiber Paper 1400C 200K Fireproof Ceramic Fiber PaperNegotiableMOQ: 200 Rolls
-
1260C 200K Fire Resistant Chemical Corrosion Resistance Ceramic Fiber PaperNegotiableMOQ: 200 Rolls
-
China Ceramic Fiber Paper Ceramic Fibre Paper Used in Car Industry Quality ChoiceUS$ 1 - 30MOQ: 100 Rolls
-
Fire Resistant Paper Fireproof Paper Ceramic Wool PaperUS$ 1 - 30MOQ: 100 Rolls
Specifications
width 610mm 1220mm ceramic fiber paperthickness 0.5-7mm kinds of length
1260C 1400C density 180-200kg/m3
Product Series:
1.1260 Ceramic Fiber Paper YXTX-236
2. 1400 Ceramic Fiber Paper YXTX-336
Description:
1. YAOXING Ceramic Fiber Paper is processed from the high purity fiber, which can be used in the field of high temperature insulation. Because we have adopted the advanced processing work, we cannot only make the fiber interweave shapely, but also can control the thickness and the density rigidly.
2. A spot of bonding agent has been added into the fiber during processing, which has been chosen and controlled scientifically, can be burnt during application.
Characteristic:
1. Low Heat Storage
2. Low Thermal Conductivity
3. Excellent Thermal Electrical Insulation
4. Excellent Machine-processed Capability
5. Excellent Broken Resistance
6. Excellent Flexibility
7. Low Shot Content
Application:
1. Industrial insulating ,sealing and protecting materials
2. Electric and thermal insulation materials for electric industry
3. Insulation materials for instrument-equipment
4. Insulating materials for motor industry
5. Filling materials for expansion slot
6. Insulating materials as the sinter resistance
7. Sealing gasket for molten metal
8. Fireproof materials
Technical Index:
Classification Temperature |
1260 |
1400 |
||
Name |
ST Ceramic Fiber Paper |
HZ Ceramic Fiber Paper |
||
Code |
YXTX-236 |
YXTX-336 |
||
Shrinkage on Heating (%) |
1000°C×24h ≤-3 |
1350°C×24h≤-3 |
||
|
Theoretical Thermal Conductivity (W/m·k) |
(200°Caverage) (400°Caverage) (600°Caverage) |
0.075-0.085 0.110-0.121 0.160-0.170 |
||
Organic Content (%) |
≤ 10 |
≤ 8 |
||
Theoretical Density (kg/m3) |
200±15 |
|||
Tensile Strength (Mpa) |
≥0.3 |
≥0.2 |
||
Moisture Content(%) |
≤1 |
|||
Specification (mm) |
100000/12000×610/1220×0.5/7, According to your requirements |
|||
Package |
Plastic Bag Inside, Carton Box Outside |
|||
Quality Control System |
ISO9001-2000, ISO14001-1996 |
|||
