2552F 12.5lb/ft3 ceramic fiber paper
Description
1.YAOXING Ceramic Fiber Paper is processed from the high purity fiber,
which can be used in the field of high temperature insulation.
Because we have adopted the advanced processing work,
we cannot only make the fiber interweave shapely,
but also can control the thickness and the density rigidly.
2.A spot of bonding agent has been added into the fiber during processing,
which has been chosen and controlled scientifically, can be burnt during application.
2552F 12.5lb/ft3 ceramic fiber paper
Technical Index
ClassificationTemperature |
1260 |
1400 |
Code |
YXTX-236 |
YXTX-336 |
|
Shrinkage on Heating (%) |
1000°C×24h≤-3 |
1350°C×24h≤-3 |
|
Theoretical Thermal Conductivity (W/m·k) |
0.075-0.085(200°Caverage) 0.115-0.121(400°Caverage) 0.165-0.175(600°Caverage) |
|
Theoretical Density (kg/m3) |
200±15 |
200±15 |
Specification (mm) |
100000/12000×610/1220×0.5/7, According to your requirements |
|
Tensile Strength(MPa) |
≥0.04 |
|
AL2O3(%) |
45-46 |
38~47 |
ZrO2(%) |
- |
15~17 |
AL2O3+SiO2(%) |
≥97 |
— |
AL2O3+SiO2+ZrO2(%) |
— |
≥99 |
Fe2O3(%) |
≤1.0 |
≤0.2 |
K2O+Na2O(%) |
≤0.5 |
≤0.2 |
Package |
Plastic Bag Inside, Carton Box Outside |
|
Quality Control System |
ISO9001-2000, ISO14001-1996 |
|
Size:
1.0.5mmX610/1220mmX90meters
2.0.7mmX610/1220mmX80meters
3.1mm X610/1220mmX60meters
4.2mm X610/1220mmX30meters
5.3mm X610/1220mmX20meters
6.4mm X610/1220mmX15meters
7.5mm X610/1220mmX12meters
Characteristic:
1.Low Heat Storage
2.Low Thermal Conductivity
3.Excellent Thermal Electrical Insulation
4.Excellent Machine-processed Capability
5.Excellent Broken Resistance
6.Excellent Flexibility
7.Low Shot Content
Application:
1.Industrial insulating ,sealing and protecting materials
2.Electric and thermal insulation materials for electric industry
3.Insulation materials for instrument-equipment
4.Insulating materials for motor industry
5.Filling materials for expansion slot
6.Insulating materials as the sinter resistance
7.Sealing gasket for molten metal
8.Fireproof materials
