C517 CE Single Column Vertical Lathe Machine for Sale

US$ 25,000 - 27,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

CNC or Not:

Normal

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Tianjing/Shanghai/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

CNC or Not Normal

Automatic Grade Semi-Automatic

Max. Swing Diameter 700mm

Place of Origin Liaoning, China

Brand Name LFM

Model Number C517 single column vertical lathe machine

Voltage 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz

Power(W) 15kW

Dimension(L*W*H) 1938x1742x2745mm

Weight 7500kgs

Certification CE; ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

C517 conventional single column vertical lathe machine

Main Usage

Suitable of the turning ferrous, nonferrous metal and some kinds of non-metal materials with hard alloy etc.

It can make rough and accurate turning of external cylindrical surface, circular conical surface, head face, grooving, severance, and so on.

Main Features

column Vertical lathe;

With DRO and CE;

Main Technical Data

Specifications	Unit	C517 single column vertical lathe
Max. turning diameter of railhead	mm	700
Max. turning diameter of sidehead	mm	700
Max. working height	mm	700
Max. weight of workpiece	T	1.2
Table diameter	mm	600
Speed range of table	r/min	10~315
Speed-step of table		16 steps
Max. torque of table	kg·m	1000
Max. cutting resistance of railhead	kg	2000
Max. cutting resistance of sidehead	kg	1500
Total cutting resistance	kg	3150
Travel of railhead ( Horizontal)	mm	420
Travel of railhead (Vertical)	mm	600
Travel of sidehead ( Horizontal)	mm	500
Travel of sidehead (Vertical)	mm	700
Travel of crossbeam	mm	420
Moving degrees limit of railhead	°	±30°
Feed range of railhead/sidehead	mm/min	0.8~86
Feeding step of the railhead and sidehead		12
Rapid traveling speed of railhead/sidehead	mm/min	1800
Traveling speed of crossbeam	mm/min	440
Power of feeding motor	KW	1.3/1.8
Power of main motor	KW	15
Overall dimensions (L×W×H)	mm	2080×2621×3515(with sidehead) 1938×1742×2745(without sidehead)
