Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CW6636x3000 Large Spindle Bore Manual Oil Pipe Thread Lathe

CW6636x3000 Large Spindle Bore Manual Oil Pipe Thread Lathe

US$ 92,500 - 94,978 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Tianjing/Shanghai/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 1000mm

Place of Origin Liaoning, China

Brand Name LFM

Model Number CW6636x3000 oil pipe thread lathe

Voltage Customer's Requirement

Power(W) 22kW

Dimension(L*W*H) 6100x1980x1790mm

Weight 12.5tons

Certification CE; ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

CW6636x3000 oil pipe thread lathe

Main Usage

mainly used for processing inner and outer pipe thread, metric thread and inch thread,

and can also undertake various turning works such as turning inner and outer cylindrical surface, conical surface and other revolution and end surface as general lathes.

Main Technical Data

Specifications	Unit	Parameter
Max. swing over bed	mm	1000
Max. swing over carriage	mm	640
Distance between two centers	mm	3000
Width of bed	mm	755
Diameter of spindle inner hole	mm	360
Range of spindle speed	r.p.m.	6.3 ~315 with 18 steps
Min. clamped diameter of chuck	mm	240
Main motor power	kW	22
Kind of metric thread and pitch range 44 kinds	mm	1~120
Kind of Whitworth thread and range		30 ~ 1.125 teeth/in (37 kinds)
Kind of modular thread and range	mm	0.5 ~ 60with (46 kinds)
Kind of radial thread and range 46 kinds	D.P.	0.5 ~60
Toolpost		With 4 way
Tool section ( H×W )	mm	45×45
Max. travel of tool post	mm	300
Max. travel of cross slide	mm	520
Rapid traverse of tool post longitudinal	mm/min	3740
Cross	mm/min	1870
Up tool post	mm/min	935
Diameter of tailstock sleeve	mm	160
Travel of tailstock sleeve	mm	300
Taper for taper hole of tailstock sleeve		Metric No. 80
Machining length of taper scale	mm	300(Taper turning±1:4)
Net dimension of machine	mm	6100×1980×1790
Net weight of machine	KG	12500

Free Std Accessories

Name	Size	Note
4-jaw manual chuck with steel body	dia. of 800 mm	2 sets
Steady rest (fixed steady)	range 50 to 470 mm with bearing type	1 set
Follow rest (traveling steady with tips)	Range 50 to 220 mm	1 set
Cooling system		1 set
Lighting device		1 set
Taper turning device	length 300 mm	1 set
Living center		1 set
Dead center		1 piece
Center sleeve		1piece
Set of machine operating tools
