XD30/40 cnc vertical milling machine Technical Data
Such cnc vertical milling machine has following features:
1. The basic parts, including in machine floor, column, spindle box, cross slide and work-table, are casted with high rigidity cast-iron, so that guarantees s stable structure and ever high quality.
2. High-speed, high-accuracy spindle;
3. X, Y, Z axes are all equipped with Sliding Guide and high-precision ballscrew which is pre-tensioned to enhance the rigidity to eliminate the deformation, which is caused by the high temperature as the spindle rotating at high speed.
4. The machine has characteristics of high-Automation, reliability, convenience, easy operation, suitability and handsome appearance together with heavy duty
5. CE Standard and CE Certificate;
1. Milling, boring, drilling, reaming and tapping can be performed in one set-up.
2. widely used in various industries of military, aviation, car manufacturing and molding.
XD30/40 cnc vertical milling machine's technical information:
Item |
XD30A |
XD40A |
Table(L×W)(mm) |
700×320 |
800×420 |
T-slot(Numbers × Width × Distance)(b/t slots) |
3×14×110 |
3×18×125 |
Table load Max(kg) |
350 |
500 |
The distance from spindle center line to column guide way surface(mm) |
430 |
511 |
The distance from spindle nose end face to table upper surface(mm) |
140-520 |
150-670 |
X/Y/Z travel(mm) |
450/350/380 |
600/420/520 |
X/Y/Z guide way type |
Linear way |
|
X/Y/Z rapid traverse speed(m/min) |
30/30/30 |
24/24/20 |
Feedrate(mm/min) |
1-10000 |
|
X/Y/Z servo motor power(Nm) |
11/11/11 |
12/12/12 |
Spindle motor power(kW) |
5.5/7.5 |
7.5/11 |
Spindle speed range(r/min) |
60-10000 |
60-8000 |
Spindle taper |
#40(7/24) |
|
|
|
|
X/Y/Z Positioning accuracy(mm) |
0.016 |
X/Z:0.02 Y:0.016 |
Air pressure requirement (mPa) |
0.5 |
0.6 |
Overall dimension(L×W×H) |
2300×2000×2200 |
2510×2040×2337 |
Net weight (kg) |
2400 |
4000 |
