Ceramic Fiber Module YAO XING modules are made from ceramic fiber blanket stacked with cut edges exposed, and anchor systems to enable quick, easy and efficient installation in most furnace linings. These prefabricated modules are designed to meet the thermal insulation requirements of high temperature furnaces. | |
|
Advantages
1. Excellent thermal and physical stability 6. Fast and easy installation
Availabilities 300mm x 300mmx 200~300mm (Thickness) Custom sizes available upon request
|
Applications
1.Oil heaters 2.Reformer 6.Crude oil heaters
|
Technical Index:
|
Classification Temperature |
1050 |
1260 |
1400 |
||
Code |
YXTX-189 |
YXTX-289 |
YXTX-389 |
TXTX-489 |
TXTX-589 |
|
Shrinkage on Heating(%) |
950°C×24h≤-3 |
1000°C×24h≤-3 |
1100°C×24h≤-3 |
1200°C×24h≤-3 |
1350°C×24h≤-3 |
|
Theoretical Density (kg/m3) |
200±10 |
||||
|
Shot Content (φ≥0.25mm)(%) |
≤15 |
||||
|
Theoretical Thermal Conductivity (W/m·k) |
0.050-0.060(200°C) |
||||
0.095-0.120(400°C) | |||||
0.160-0.195(600°C) | |||||
Al2O3 (%) |
≥44 |
≥45 |
≥45 |
52-55 |
38-40 |
Al2O3+SiO2 (%) |
≥96 |
≥97 |
≥99 |
≥99 |
- |
ZrO2 (%) |
- |
- |
- |
- |
15-17 |
Al2O3+SiO2+ ZrO2 (%) |
- |
- |
- |
- |
≥99 |
Fe2O3 (%) |
≤1.2 |
≤1.0 |
≤0.2 |
≤0.2 |
≤0.2 |
K2O+Na2O (%) |
≤0.5 |
≤0.5 |
≤0.2 |
≤0.2 |
≤0.2 |
Specification (mm) |
300×300×200,According to your requirements |
||||
Package |
Woven Bag/Carton |
||||
|
Quality Control System |
ISO9001-2000 ,ISO14001-1996 |
||||
