Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Grade:
HP (High Pure)
Application:
Liners Of Industrial Furnace, Drop tube furnace
Thickness:
200-300mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Grade HP (High Pure)
Thickness 200-300mm
Width 300mm
Length 300mm
Chemical Composition AL2O3≥44%, AL2O3+SiO2≥97%
Working Temperature 1000℃
Fiber Diameter 3μm
Shrinkage (1800 ℉, 3h) <3%
Thermal Conductivity 0.050-0.060
Model Number YXTX-389
Brand Name YAOXING
Place of Origin Shandong, China







Product Description



 Product Series:







1.1050 Ceramic Fiber Module YXTX-189



2.1260 Ceramic Fiber Module YXTX-289



3.1260 Ceramic Fiber Module YXTX-389



4.1400 Ceramic Fiber Module YXTX-489



5.1400 Ceramic Fiber Module YXTX-589







Technical Index:





Classification Temperature

1050

1260

1400

Code

YXTX-189

YXTX-289

YXTX-389

TXTX-489

TXTX-589

Shrinkage on Heating (%)

950℃×24h

≤-3

1000℃×24h

≤-3

1100℃×24h

≤-3

1200℃×24h

≤-3

1350℃×24h

≤-3

Theoretical Density (kg/m3)

200±10

Shot Content

(φ≥0.25mm)(%)

≤15

Theoretical

Thermal Conductivity

(W/m·k)

0.050-0.060(200℃)

0.095-0.120(400℃)

0.160-0.195(600℃)

 Al2O3 (%)

≥44

≥45

≥45

52-55

38-40

Al2O3+SiO2 (%)

≥96

≥97

≥99

≥99

-

ZrO2 (%)

-

-

-

-

15-17

Al2O3+SiO2+ ZrO2 (%)

-

-

-

-

≥99

Fe2O3 (%)

≤1.2

≤1.0

≤0.2

≤0.2

≤0.2

K2O+Na2O (%)

≤0.5

≤0.5

≤0.2

≤0.2

≤0.2

 Specification (mm)

300×300×200,According to your requirements

Package

Woven Bag/Carton

Quality Control System

ISO9001-2000 ,ISO14001-1996





Application:





Furnace lines of various industrial furnace and heating equipment in metallurgy,

machine, construction and material, petrol-chemical and ferrous metal industry.



1.Oil heaters



2.Reformer



3.Forge furnaces



4.Process heaters



5.Preheating furnaces



6.Crude oil heaters



7.Fume incinerators



8.Tunnel kilns



9.Cracking Furnaces



10.Shuttle kilns



11.Annealing furnaces
