Home > Chemicals > Inorganic Fiber > Ceramic Fiber > Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module

Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module

Name: Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module
Brand: YAOXING
SKU: 102718183
Availability: InStock

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-1$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-2$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-3$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-4$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-5$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module thumbnail-6$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-1$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-2$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-3$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-4$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-5$

$Thermal Insulation Material for Oven Ceramic Fiber Module Refractory Module photo-6$

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Grade:

HZ (High Zirconium)

Application:

Liners Of Industrial Furnace, Heat Insulation

Thickness:

200-300mm

Contact Supplier Request Quote Chat Now

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Grade HZ (High Zirconium)

Thickness 200-300mm

Width 300mm

Length 300mm

Chemical Composition AL2O3≥38%,ZirO2≥15%, AL2O3+SiO2+ZirO2≥99%

Working Temperature 1350℃

Fiber Diameter 3μm

Shrinkage (1800 ℉, 3h) <3%

Thermal Conductivity 0.050-0.060

Model Number YXTX-589

Brand Name YAOXING

Place of Origin Shandong, China

Product Description

Characteristic

Ceramic fiber folded module not only used in furnace, but also brought following benefit with ended custom

Folded blanket will impact tight with each other in differently way without gaps after release from packing.
Elastically fiber blanket can withstand mechanical force.
The elasticity of fiber blanket could make up distortion of furnace casing and with gaps between modules.
Because of the light weight, the decalescence capability is low as the insulation materials.
Low thermal conductivity can save much energy.
Excellent thermal shock resistance capability.
Can be betaken immediately as soon as being installed, for there is no need to be dried and maintained.
The Anchor system should be far away from the hot surface of the modules and kept in the lower temp.

Technical Index

Classification Temperature	1050	1260		1400
Code	YXTX-189	YXTX-289	YXTX-389	TXTX-489	TXTX-589
Shrinkage on heating (%)	950°C×24h≤-3	1000°C×24h≤-3	1100°C×24h≤-3	1200°C×24h≤-3	1350°C×24h≤-3
Theoretical density (kg/m³)	200±10
Shot content (φ≥0.25mm)(%)	≤15
Theoretical Thermal conductivity (W/m·k)	0.050-0.060(200°C)
	0.095-0.120(400°C)
	0.160-0.195(600°C)
Al₂O₃(%)	≥44	≥45	≥45	52-55	38-40
Al₂O₃+SiO₂(%)	≥96	≥97	≥99	≥99	-
ZrO₂(%)	-	-	-	-	15-17
Al₂O₃+SiO₂+ ZrO₂(%)	-	-	-	-	≥99
Fe₂O₃(%)	≤1.2	≤1.0	≤0.2	≤0.2	≤0.2
K₂O+Na₂O (%)	≤0.5	≤0.5	≤0.2	≤0.2	≤0.2
Specification (mm)	300×300×200,According to your requirements
Package	Woven Bag/Carton
Quality Control System	ISO9001-2000 ,ISO14001-1996
