Fire Board Ceramic Fiber Board Thermal Ceramic Board

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-1
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-2
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-3
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-4
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-5
Fire Board Ceramic Fiber Board Thermal Ceramic Board thumbnail-6
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-1
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-2
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-3
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-4
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-5
Fire Board Ceramic Fiber Board Thermal Ceramic Board photo-6
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Application:
Liners Of Industrial Furnace, Fireproof Materials
Thickness:
10-50mm
Width:
400/600/1000mm
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Thickness 10-50mm
Width 400/600/1000mm
Length 600/1000mm
Grade HA (High Aluminum)
Chemical Composition AL2O3≥52%, AL2O3+SiO2+ZirO2≥99%
Working Temperature 1200℃
Fiber Diameter 3μm
Thermal Conductivity 0.103
Shrinkage (1800℉, 3h) <3%
Place of Origin Shandong, China
Model Number YXTX-434
Brand Name YAOXING







Product Description





YXTX-234,YXTX-334 CERAMIC FIEBR BOARD





Technical Index



Name

High Aluminum

 Ceramic Fiber Board

High Zirconium

Ceramic Fiber Board

Code

YXTX-434

YXTX-534

Shrinkage on Heating (%)

1200×24h≤-3

1350×24h≤-3

Theoretical

Thermal

Conductivity

 W/(m·k)

(200°Caverage)

(400°Caverage)

(600°Caverage)



0.103

0.125

0.151

Compressive Strength,≥(Mpa)

0.5

Theoretical Density (kg/m3)

220-500

Moisture Content(%)

≤1

Organic Content(%)

≤8

Specification (mm)

1200×1000×10,According to your requirements

Package

Plastic Bags inside, Carton outside

Quality Control System

ISO9001-2000   ISO14001-1996









Characteristic



Low Heat Storage,low thermal conductivity



Excellent compressive strength



Not fragile materials, excellent flexibility



Exact measurement,excellent flatness



Homogeneous structure, excellent machine-processed capability



Easily fixing specialty



Processed continuously,the fibers interweave shapely and excellent stability



Excellent chemical stability and thermal shock resistance



Application:



1.Heat preservation and insulation materials as the back lines for the kilns

in the field of cement building



2.Heat preservation materials as the back lines for the kilns in the field of ceramic



3.Heat preservation materials as the wall lines and back lines for the kilns

in the field of metallurgy and petrochemical industry



4.Heat preservation materials as the wall lines and back lines for the Glass furnace.



5.Refractory and insulating materials for heat treatment equipment



6.The back lines of refractory brick for electrolytic reducing bath in aluminum factory



7.Materials of  the wall lines and back lines of heat and pyroreaction equipment
