Specifications
refractory ceramic fiber board1.specifaction:1000*600*10-50mm
2.density:220-400kg/m3
ing temp:1050C 1260C 1400C
Product Series:
1.YAOXING 1050 Ceramic Fiber Board YXTX-134
2.YAOXING 1260 Ceramic Fiber Board YXTX-234
3.YAOXING High Pure Ceramic Fiber Board YXTX-334
4.YAOXING High Aluminum Ceramic Fiber Board YXTX-434
5.YAOXING High Zirconium Ceramic Fiber Board YXTX-534
Description:
1.YAOXING 1050/1260 Ceramic Fiber Board was processed by the advanced production line,
which was adopted the full automatic control and the continuous- processing method.
2.YAOXING 1050/1260 Ceramic Fiber Board have many typical characteristics, such as exact
measurement,excellent toughness,excellent heat preservation and can be cut discretionally
3.The processing work is much advanced, which totally avoid the long production cycle and the
low production capacity.
4.YAOXING 1050/1260 Ceramic Fiber Board is divided in different series by the temperature,
can be widely used as the back lining of industrial furnace and the hot surface of the low
temperature furnace. It is one of the guarantees of reaching the energy conservation and the high
quality.
Characteristic:
Low Heat Storage
low thermal conductivity
Excellent compressive strength
Not fragile materials
Excellent flexibility
Exact measurement
Excellent flatness
Homogeneous structure
Excellent machine-processed capability
Easily fixing specialty
Processed continuously,the fibers interweave shapely
Excellent stability
Excellent chemical stability and thermal shock resistance
Technical Index:
Name | CO | ST | HP |
Code | YXTX-134 | YXTX-234 | YXTX-334 |
Shrinkage on Heating (%) | 950×24h≤-3 | 1000×24h≤-3 | 1100×24h≤-3 |
Theoretical Thermal Conductivity W/(m·k) | 0.060-0.085(200°Caverage) 0.092-0.112(400°Caverage) 0.112-0.126(600°Caverage)
| ||
Compressive Strength ≥(Mpa) | 0.5 | ||
Theoretical Density (kg/m3) | 220-320 | 220-400 | 220-450 |
Moisture Content (%) | ≤1 | ||
Organic Content (%) | ≤8 | ||
Specification (mm) | 1200/1000/900/600×1000/600/400×10/20/30/40/50 According to your requirements | ||
Package | Plastic Bags inside, Carton outside | ||
Quality Control System | ISO9001-2000 ISO14001-1996 | ||
Application:
Heat preservation and insulation materials as the back lines for the kilns in the field of cement
building
Heat preservation materials as the back lines for the kilns in the field of ceramic
Heat preservation materials as the wall lines and back lines for the kilns in the field of
metallurgy and petrochemical industry
Heat preservation materials as the wall lines and back lines for the Glass furnace.
Refractory and insulating materials for heat treatment equipment
The back lines of refractory brick for electrolytic reducing bath in aluminum factory
Materials of the wall lines and back lines of heat and protection equipment
Loading
Specification (MM) | Density (KG/M3) | NW/CNT (KG) | CNT Size (MM) | QTY/CNT (PCS) | CONT Size (FOOT) | PCS/CONT (CNTS) |
900*600*10 | 300-350 | 1.62-1.89 | 910*610*220 | 20 | 20 | 240 |
900*600*20 | 300-350 | 1.62-1.89 | 910*610*220 | 10 | 40GP | 489 |
900*600*50 | 300-350 | 1.62-1.89 | 910*610*220 | 4 | 40HQ | 592 |
