Help CenterRefractory Heat Ceramic Fiber Board High Pure Ceramic Wool Board Fireplace Ceramic Fiber Board
Related Products
-
Oven Heat Insulation Board Aluminum Silicate Ceramic Fiber Board Inorganic Ceramic Fiber BoardNegotiableMOQ: 100 Cartons -
Fireproof Insulation Board for Kiln Heat Resistant Insulation Fireproof Insulation BoardNegotiableMOQ: 1000 Pieces
-
Heat Resistant Insulation Ceramic Fiber Board Furnace LiningsNegotiableMOQ: 100 Pieces
-
Heat Insulation Ceramic Fiber Board Heat Insulation of Steam Heat Insulation Ceramic Fiber BoardNegotiableMOQ: 100 Pieces
-
High Temperature Resistance Alumina Ceramic TileNegotiableMOQ: 100 Pieces
Technical Index
Type |
Common |
Standard |
HP |
HA |
HZ |
|
Code |
YXTX-134 |
YXTX-234 |
YXTX-334 |
YXTX-434 |
YXTX-534 |
|
|
Classification Temperature |
1050 |
1260 |
1260 |
1400 |
1400 |
|
|
Shrinkage on Heating (%) |
950°C×24h ≤-3 |
1000°C×24h ≤-3 |
1100°C×24h ≤-3 |
1200°C×24h ≤-3 |
1350°C×24h ≤-3 |
|
|
Theoretical Thermal Conductivity (W/m·k) (128kg/m3) |
(200°Caverage) (400°Caverage) (600°Caverage) |
0.045-0.060 0.085-0.110 0.152-0.20 |
0.052-0.070 0.095-0.120 0.164-0.210 |
|||
|
Theoretical Density (kg/m3) |
96/128 |
128 |
96/128 |
|||
Specification (mm) |
1200/1000/900/600×1000/600/400×10/20//30/40/50 According to your requirements |
|||||
|
Tensile Strength (25mm thick)MPa |
0.5 |
|||||
AL2O3(%) |
≥44 |
≥45 |
≥45 |
52~55 |
38~40 |
|
ZrO2((%) |
- |
15~17 |
||||
AL2O3+SiO2(%) |
≥96 |
≥97 |
≥99 |
≥99 |
— |
|
AL2O3+SiO2+ZrO2(%) |
— |
— |
— |
— |
≥99 |
|
Fe2O3(%) |
≤1.2 |
≤1.0 |
≤0.2 |
≤0.2 |
≤0.2 |
|
K2O+Na2O(%) |
≤0.5 |
≤0.5 |
≤0.2 |
≤0.2 |
≤0.2 |
|
Package |
Plastic Bag Inside, Carton Box Outside |
|||||
Quality Control System |
ISO9001-2000, ISO14001-1996 |
|||||
Application
1.Heat preservation and insulation materials as the back lines for the kilns
in the field of cement building
2.Heat preservation materials as the back lines for the kilns in the field of ceramic
3.Heat preservation materials as the wall lines and back lines for the kilns
in the field of metallurgy and petrochemical industry
4.Heat preservation materials as the wall lines and back lines for the Glass furnace.
5.Refractory and insulating materials for heat treatment equipment
6.The back lines of refractory brick for electrolytic reducing bath in aluminum factory
7.Materials of the wall lines and back lines of heat and pyroreaction equipment
