Help CenterHeat Resistant Insulation Ceramic Fiber Board Furnace Linings
Related Products
-
Heat Insulation Ceramic Fiber Board Heat Insulation of Steam Heat Insulation Ceramic Fiber BoardNegotiableMOQ: 100 Pieces -
High Temperature Resistance Alumina Ceramic TileNegotiableMOQ: 100 Pieces
-
Insulation for Steam PipeNegotiableMOQ: 100 Cartons
-
Refractory Insulation Board Ceramic Fiber Board Heat Insulation Ceramic Fiber BoardNegotiableMOQ: 1 Metric Ton
-
Oven Insulation Board Vacuum Ceramic Fiber Board Furnace Ceramic BoardNegotiableMOQ: 100 Cartons
Technical Index
Type | CO | ST | HP | HA | HZ | |
Code | YXTX-134 | YXTX-234 | YXTX-334 | YXTX-434 | YXTX-534 | |
Classification Temperature | 1050 | 1260 | 1260 | 1400 | 1400 | |
Shrinkage on Heating (%) | 950°C×24h≤-3 | 1000°C×24h≤-3 | 1100°C×24h≤-3 | 1200°C×24h≤-3 | 1350°C×24h≤-3 | |
Theoretical Thermal Conductivity (W/m·k)(128kg/m3) | (200°Caverage) (400°Caverage) (600°Caverage) | 0.045-0.060 0.085-0.110 0.152-0.20 | 0.052-0.070 0.095-0.120 0.164-0.210 | |||
Theoretical Density (kg/m3) | 96/128 | 128 | 96/128 | |||
Specification (mm) | 1200/1000/900/600×1000/600/400×10/20//30/40/50 According to your requirements | |||||
Tensile Strength (25mm thick)MPa | 0.5 | |||||
AL2O3(%) | ≥44 | ≥45 | ≥45 | 52~55 | 38~40 | |
ZrO2((%) | - | 15~17 | ||||
AL2O3+SiO2(%) | ≥96 | ≥97 | ≥99 | ≥99 | — | |
AL2O3+SiO2+ZrO2(%) | — | — | — | — | ≥99 | |
Fe2O3(%) | ≤1.2 | ≤1.0 | ≤0.2 | ≤0.2 | ≤0.2 | |
K2O+Na2O(%) | ≤0.5 | ≤0.5 | ≤0.2 | ≤0.2 | ≤0.2 | |
Package | Plastic Bag Inside, Carton Box Outside | |||||
Quality Control System | ISO9001-2000, ISO14001-1996 | |||||
Characteristic:
- Low Heat Storage,low thermal conductivity
- Excellent compressive strength
- Not fragile materials, excellent flexibility
- Exact measurement,excellent flatness
- Homogeneous structure, excellent machine-processed capability
- Easily fixing specialty
- Processed continuously,the fibers interweave shapely and excellent stability
- Excellent chemical stability and thermal shock resistance
Application:
1.Heat preservation and insulation materials as the back lines for the kilns
in the field of cement building
2.Heat preservation materials as the back lines for the kilns in the field of ceramic
3.Heat preservation materials as the wall lines and back lines for the kilns
in the field of metallurgy and petrochemical industry
4.Heat preservation materials as the wall lines and back lines for the Glass furnace.
5.Refractory and insulating materials for heat treatment equipment
6.The back lines of refractory brick for electrolytic reducing bath in aluminum factory
7.Materials of the wall lines and back lines of heat and protection equipment
Plastic bags inside,carton outside
