Help CenterCNC Linear Way Vertical Machining Center Hot-sale VDL600
Related Products
-
CE 4-axis Linear Way and Box Way Vertical Machining Center Hot-sale VDL600US$ 34,780 - 108,060MOQ: 1 Set -
VDF Series Box-way Vertical Machining Center With CEUS$ 45,332 - 108,060MOQ: 1 Set
-
CE Certified Linear Way and Box Way Vertical Machining Center Hot-sale VDL600US$ 33,780 - 108,060MOQ: 1 Set
-
MDH100 OKK Cnc Horizontal Machining Center Made in ChinaUS$ 454,132 - 508,060MOQ: 1 Set
-
CE Vertical Machining Center With Linear Guide Way Hot-sale VDL1000US$ 34,780 - 108,060MOQ: 1 Set
Main Features:
l With CE Certificate;
l National Inspection-free products
l Highly rigid and stable machine structure;
l High precision slide ways on three-axis;
l High speed, high-precision spindle;
l Fast and reliable tool changing mechanism,
l Cooling system;
l Multi-function CNC control system;
Item |
VDF850 |
VDF1000 |
VDF1200 |
VDF1500 |
VDF1800 |
Table(L×W)(mm) |
1000×500 |
1120×560 |
1220×620 |
1700×800 |
2000×800 |
T-slot(Numbers × Width × Distance) (b/t slots) |
5×18×100 |
5×18×100 |
5×18×100 |
6×18×125 |
6×18×125 |
Table load Max(kg) |
500 |
750 |
1200 |
2500 |
2500 |
The distance from spindle center line to column guide way surface(mm) |
550 |
629 |
660 |
850 |
850 |
The distance from spindle nose end face to table upper surface(mm) |
150660 |
135~735 |
90~765 |
200~962 |
180~942 |
X/Y/Z travel(mm) |
850/510/510 |
1020/560/600 |
1200/600/675 |
1530/800/762 |
1850/800/762 |
X/Y/Z guide way type |
box way |
box way |
box way |
box way |
box way |
X/Y/Z rapid traverse speed(m/min) |
20/20/18 |
24/24/18 |
20/20/18 |
15/15/12 |
15/15/12 |
Feedrate (mm/min) |
17600 |
1~10000 |
1~10000 |
1~6000 |
1~6000 |
Positioning accuracy |
X0.025 YZ0.020 |
X0.025 YZ0.020 |
X0.030 YZ0.020 |
X0.030 YZ0.020 |
X0.030 YZ0.020 |
Repeat positioning accuracy |
X0.010 YZ0.008 |
X0.010 YZ0.008 |
X0.013 YZ0.008 |
X0.013 YZ0.008 |
X0.013 YZ0.008 |
X/Y/Z servo motor power(Nm) |
12/12/12 |
12/12/12 |
22/22/22 |
22/22/22 |
22/22/22 |
Spindle motor power(kW) |
7.5/11 |
7.5/11 |
11/15 |
11/15 wide range motor |
11/15 wide range motor |
Spindle speed range(r/min) |
60~8000 |
60~8000 |
45~6000 |
45~6000 |
45~6000 |
Spindle taper |
#40(7/24) |
#40(7/24) |
#50(7/24) |
#50(7/24) |
#50(7/24) |
Tool magazine capacity/Type |
20/drum |
20/drum |
24/swing arm |
24/swing arm |
24/swing arm |
Tool adaptor type |
|
BT40 |
BT50 |
BT50 |
BT50 |
Max. Tool weight(kg) |
7 |
7 |
15 |
15 |
15 |
Max. Tool diameter/length(mm) |
77/305 |
77/305 |
127/305 |
110/350swingarm |
110/350swingarm |
Time of tool change(T-T)(sec) |
6~8/3 |
6~8/3 |
3.5 |
3.5 |
3.5 |
Air pressure requirement (mPa) |
0.5 |
0.6 |
0.6 |
0.6 |
0.6 |
Power requirement (kW) |
25 |
25 |
35 |
40 |
40 |
Overall dimension(L×W×H) |
3350×2280×2650 |
2820×2820×2477 |
2880×2815×2791 |
4300×3480×3120 |
5160×3480×3120 |
Net weight (kg) |
7000 |
8000 |
8500 |
14000 |
14500 |
