Help CenterCKE6150(500mm) CNC Horizontal Lathe Machine With CE
Related Products
-
Mid-sized Horizontal CNC Lathe Hot-sale CKE6150 Hot-saleUS$ 19,717 - 35,000MOQ: 1 Set -
CKE6180/100/125M Large CNC Flat Bed Lathe With CEUS$ 27,706 - 144,912MOQ: 1 Set
-
CKE61100M Large Flat Bed CNC Lathe With CE(Load:1500kgs)US$ 95,380 - 109,394MOQ: 1 Set
-
Large CNC Flat Bed Lathe With CEUS$ 31,000 - 109,394MOQ: 1 Set
-
CKE6163(Z)x5000 Flat Bed CNC Lathe With CEUS$ 52,484 - 64,245MOQ: 1 Set
CKE6150 CNC Flat-bed Lathe Machine
- All main components, bed, headstock, saddle, plinth, etc., are high-quality solid castings.
- Low friction Turcite-B coating on mating surfaces between saddle and guideways.
- Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
- Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
- Choice of two model ranges. The CKE-Z series has automatic headstock gear changing, high spindle speed with wide range, and low noise levels of under 80db.
- The CKE-I series, with independent spindle structure, utilizes a frequency converted spindle motor or servomotor to offer stepless high spindle speeds.
- Operator adjustable control panel enables convenient tool setting.
- Fully enclosed guards with interlock offer a waterproof and chip-free environment.
- Horizontal /vertical 4-P automatic tool post is provided as standard, while vertical 4-P indexing tool post, horizontal 6/8-P tool post, quick-change toolpost, etc can also be supplied to suit customers' specific requirements.
- Optional pneumatic or hydraulic chuck and tailstock are available.
- FANUC, SIEMENS, FAGOR, etc control systems can be supplied.
- E-hand wheel function is also available.
- 3 kinds of main motors for your choice: 2-speed main motor; varaible-frequency main motor and Servo main motor;
Item |
Specifications |
Unit |
Parameter |
|
Max. length of work piece |
mm |
750/1000/1500/2000 |
Max. machining dia.(4-position turret) |
mm |
500 |
|
Max. machining dia.(Horizontal 6-position turret) |
mm |
400 |
|
Max. swing over bed |
mm |
500 |
|
Max. swing over slide |
mm |
300 |
|
X travel |
mm |
260 |
|
Z travel |
mm |
750/1000/1500 |
|
Spindle speed |
rpm |
2200 |
|
Spindle nose |
|
ISO A2-8 |
|
Taper of spindle bore |
Morse |
1:20 |
|
Spindle bore |
mm |
82 |
|
Frequency conversion motor power |
kW |
11 |
|
Rapid traverse X/Z |
m/min |
8/12 |
|
Positioning accuracy |
mm |
X: 0.025 Z:0.035 |
|
Repeat positioning accuracy |
mm |
X: 0.010 Z:0.012 |
|
CNC System |
|
GONA GDS07 |
|
Net weight |
kg |
3500 |
|
Overall dimensions |
mm |
2430/3430/3930 ×1620×1700 |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Delivery Time:
- Normally, 30~60 days, however, different sizes of machines, delivery time will be different, pls consult for exact machine.
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
