Help Center900V 1100uF 1100MFD 105C High Power DC Link Capacitor
Related Products
-
Replacement of PK16 XC E50.R16-175NT0 700V 1680uF 1680MFD 1700uF 1700MFD AC Filter CapacitorUS$ 5 - 99MOQ: 10 Pieces -
Equivalent to PK16 XC E50.N18-115NT0 700V 1075uF 1075MFD 1100uF 1100MFD IGBT Snubber CapacitorUS$ 5 - 99MOQ: 10 Pieces
-
Direct Cross to PK16 XC E50.N14-834NZ0 700V 825uF 825MFD 800uF 800MFD High Frequency Power CapacitorUS$ 5 - 99MOQ: 10 Pieces
-
Replacements of PK16 XC E50.N13-754NT0 700V 750uF 750MFD Low ESR DC Link CapacitorUS$ 5 - 99MOQ: 10 Pieces
-
Alternative for PK16 XC E50.N11-594NT0 700V 585uF 585MFD 590uF 590MFD 600uF 600MFD DC Filter CapacitorUS$ 5 - 99MOQ: 10 Pieces
1, Germany quality
2, Factory price
3, Fast delivery
4, Low cost shipping solutions
5, Samples available for evaluate
6, World class customers experience
Product name: 900V 1100uF 1100MFD 105C High Power DC Link Capacitor
DC LINK Capacitor 900V 1100uF, DC power capacitor 900VDC 1100MFD, high power DC Capacitor 900V 1100mfd, Capacitor for DC LINK converter, 900V 1100uf inverter capacitor from AnXon Electronic
Rated Spec: |
900V 1100uF , 900VDC 1100mfd |
Tolerance: |
K, ±10% |
Type: |
Screw Mounting |
Dielectric : |
Metallized polypropylene film |
Operating Temperature: |
-40C ~ 85C |
Size / Dimension(ΦD×L): |
D:86mm, H:225mm |
Choose the best capacitor for any of your power electronics applications, high quality equivalent Direct cross to Electronicon PK16 XI series capcitors provided by AnXon Electronic, 600V, 700V, 800V, 900V, 1100V, 1300V, 1500V, 1800V, 2000V, 2200V, 2400V, 2600V, 2800V, 3000V, 3200V, 3600V, 4000V DC Link capacitors
AnXon Part No. |
Rated Spec |
I |
ESL |
D x L |
Equivalent to Electronicon PK16 XC P/N |
kVdc / uF |
A |
nH |
mm |
||
Un 700VDC Us 1050V Utt 1050VDC Utc 3300V AC/2s | |||||
AXCT27350K701SA |
700V 350uF |
20 |
50 |
67x114 |
E50.L11-354N40 |
AXCT27585K701CA |
700V 585uF |
30 |
60 |
85x110 |
E50.N11-594NT0 |
AXCT27750K701CA |
700V 750uF |
35 |
55 |
85x136 |
E50.N13-754NT0 |
AXCT27825K701CA |
700V 825uF |
35 |
40 |
85x146 |
E50.N14-834NZ0 |
AXCT271075K701CA |
700V 1075uF |
35 |
60 |
85x181 |
E50.N18-115NT0 |
AXCT271680K701DA |
700V 1680uF |
40 |
40 |
116x165 |
E50.R16-175NT0 |
AXCT271945K701DA |
700V 1945uF |
40 |
50 |
116x190 |
E50.R19-195NT0 |
AXCT272120K701DA |
700V 2120uF |
60 |
50 |
116x215 |
E50.R21-215NT0 |
AXCT272150K701CA |
700V 2150uF |
60 |
100 |
85x348 |
E50.N35-225NT0 |
AXCT273100K701DA |
700V 3100uF |
60 |
70 |
116x295 |
E50.R29-315NT0 |
AXCT273890K701DA |
700V 3890uF |
60 |
70 |
116x345 |
E50.R34-395NT0 |
AXCT274420K701EA |
700V 4420uF |
60 |
70 |
136x295 |
E50.S29-445NT0 |
AXCT275540K701EA |
700V 5540uF |
60 |
70 |
136x345 |
E50.S34-555NT0 |
Specifications
• Capacitance range 50μF to 7400μF
• Rated Voltage 600vdc to 4000vdc
• Capacitance Tolerance ±10%,±5%
• Dissipation factor ( Tan d) 0.0002
• Insulation Resistance MΩ x μF 5,000S @ 25°C (S = MΩ x μF)
• Dielectric strength between terminals (U ) 1.5 x rated voltage for 60 secs T-T
• Test Voltage Terminal to case (U ) Up to 4800 Vac 50 Hz T-c
• Operating Temperature: -40°C to +85°C
Features
• High RMS current
• Low ESR
• Life Expectancy 100,000 Hours
• Fully encapsulated dry construction
• Flame retardant UL94 - V0, ROHS compliant
• Reference Standard: IEC 61071 and IEC 60068
Applications
• DC Link and DC Filter applications in Power converters for
• Uninterruptible power supplies
• Wind power inverters
• Solar power inverters
• Traction and industrial drives.
• Impulse discharge capacitors for magnetizing and welding
Custom design products are available on request, please contact us for more spec details.
